4*2dongfeng Heat Preservation Fresh Milk Tanker Truck/Fresh Milk Transport Truck/Liquid Food Transpo

4*2Dongfeng heat preservation fresh milk Tanker truck/freshmilktransporttruck/Liquid Food Transport TankerTruck

Milk tanker truck, also known as milk, liquid Food Trucks, milk trucks, mainly used for transporting milk, liquid food, cooking oil and other tankers. Tank with food-grade stainless steel, the tank internal requirements clean, no acute angle, external tank insulation to prevent the need for fresh deterioration in general need to add milk in each cabin cip (cleaning device).
Milk truck/milk transport truck/milk lorry developed by our company covering SINOTRUK, DFAC, ISUZU, FAW, FOTON, JAC, JMC brand, having characteristics such as high intensity, fire retardant, waterproof, static proof, fireworks alarming.

4x2 fresh milk transportion tank truck
Main Data	Model No.	CLW5160GNY3	Axles		3
	G.V.W(Kg)	16000	Tank volume(m3)		18.9
	Curb weight(Kg)	6605	Overall dimension (mm)		8850×2490×3200
	Rated weight(Kg)	9200	Axles Load(Kg)		6000/10000
	Emission Standard	Euro III	Front/rear suspension(mm)		1430/2420,1430/2720
	Approach/departure angle (°)	20/8	Front/rear Tread(mm)		1880/1860
	Wheelbase(mm)	5000, 4700	Max speed(Km/h)		85
	Leaf of springs	7/9+6,8/10+8	Tire		9.00-20,9.00R20,10.00-20,10.00R20,275/80R22.5
Chassis mode	DFL1160BX		Fuel type		Diesel
Engine	Type	Brand	Displacement(ML)		Rated Power(Kw)
	ISDe185 30	Dongfeng cummins	6700		136
	ISDe210 30	Dongfeng	6700		155
	EQH180-33	Dongfeng	4752		132
Gearbox	9 forwarder,1 reverse gear	Brakes	dual circuit compressed air brake
Milk tank parameter	Tank Effective Volumn	11.77 m3	Inside steel thickness		3-4mm
	Middle layer	polyurethane foam:70-80mm	External material		304 stainless steel / 2mm
	warm preservation ability	±2-3ºC during 24H	Compartment		5 as standard
	Manhole	Man way access hole on top of tank;2-4 units manhole
	Tank materials	high quality food grade stainless steel (Q304/2B)
Specical fuction	1.The milk tank is made up of three layers:outside layer(for physical protection),middle layer(thermal insulation),inner layer tank(for milk filling). 2.Equipped with PIC cleaning & washing device inside the tank, washing lever, washing tube( Φ 38mm ), four or even more rotation sprayer, external water tube.Tank itsellf has wash fuction by little pressure. 3. With thermal insulation fuction to maintain temperature. 4. The tank can be divided into several parts according to demand to load different materials

Product description
Chengli Special Automobile Co., Ltd is a professional manufacturer of all kinds of special truck and trailer as well as other special equipment.
LPG tank is our most advantage key products which rank Top 5 in China, excellent engineers and high-grade production equipment as well as stricted quality control system can ensure all the tank from us run very well with 10-20 years use life.


Our main products:
1. Dump Truck / Tipper Truck/Side Tipper/End Tipper
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck Mounted Crane
4. LPG Tank Truck Trailer/Oil Tank Truck / Fuel Tanker Truck
5. Water Truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage Suction Truck,
9. Cement Powder Tank truck/ Bulk Cement Truck
10. High-altitude operation truck,
11. Self-loading Garbage Truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )


Any further inquires, feel free to contact me throught below info!
Chengli Special Automobile Co., Ltd
Factory Add:ChengliAutomobileIndustryPark,SuizhouCity,
HubeiProvince,P.R.China
Export:Room3102,Block7,FanhaiInternationalSOHOTown,
JianghanDistrict,Wuhan,HubeiProvince,China
Mob:(+86) 18607168573

1. Factory Supply:one of the biggest special purpose truck manufacturers in china,more than 300 kinds of special truck for your choice.

2. OEM Ability: according to your demand, material, dimensions, surface color and the logo are optional for you.

3. Good Quality: with ISO CCC BV certification Solid technology, advanced equipments; reliant quality and flexible modes of operation also have strict quality control system,passed the ISO9001-2008 and the 3C (China Compulsory Certification),our brand is china famous brand with good reputation in the market.

4. Best Service: 24-hour hotline and email during communication.

5. Fast Delivery: 5-10 days after payment(most common products), safe and quick delivery.

Packaging:nude with wax.

Shipping:Ro-Ro/Bulk Ship/Container
