Tri-Axles Flatbed Heay Duty Truck/Flatbed Wrecker/Flatbed Transportation Trucks/Towing Truck Wrecker

Tri-Axles flatbed heay duty truck/Flatbed Wrecker/Flatbed transportation trucks/towingtruckwrecker

3 Axles flatbed heay duty truck
Tare Weight(Kg)	25000	Overall Dimensions(LxWxHmm)	11980,11200×2500×3080
Curb weight(Kg)	9105	Axles Load(Kg)	6750/6750/11500
Front/Rear wheel Track(mm)	1942/1942,1914/1914,2020/2020 / 1847,1860	Front/Rear Overhang(mm)	1375/3055,1375/2775
Wheel base(mm)	1900+5650,1900+5150	Rear Tread(mm)	2180/2180/2180
Approch/Departure angle(.)	10/18	Drive cab	2 or 3 passengers
Leaf Spring	12/12/10+9,12/3+-/10+9	Max. Speed(km/h)	90
Chassis		CA1251P1K2L7T3EA80
Engine
Model	Manufacture	Displacement(ML)	Power(kw)
CA6DF3-22E3	China Yiqi	6740	188
BF6M1013-24E3	China Yiqi	7146	188
Specifications
I Beam& Chassis	Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes. Top Flange 18mm,width 140mm; Middle Flange 8mm,Height 500mm, Bottom Flange 20mm,width 140mm.
Axle	3 axles (BPW 13ton, FUWA, L1 brand are optional)
Suspension	Heavy duty mechanical suspension
Floor	3mm checker plate
Leaf Spring	13 piece Leaf spring
King Pin	JOST brand 2" Bolt-in King Pin
Landing Gear	JOST brand Two-speed, manual operating, heavy duty landing gear
Wheel Rim	8.25-22.5steel wheel rim
Tire	10.00-20,10.00R20,11.00-20,11.00R20
Ramp	Mechanical ramp with spring
Braking System	WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 40L air tanks
Twist Lock	12 nos. of ISO twist lock for 1x20ft, 2x20ft; 1x40ft container, the retractable central locks can be laid down.
Painting	Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
Accessories	One standard tool box

FAQ:

1.Are you a manufacturer or trading company?
We are top three of special automobile manufacturer of China.

2. Where is your factory location, and can we visit it?
Chengli group is located in Suizhou city, Hubei province, China.
It is my pleasure that if you will come to our factory, our chauffeur and me will pick you up at Wuhan international airpoort.

3. What is your MOQ (Minimum Order Quantity)?
MOQ is 1!

4. What is your payment terms?
T/T or L/C.

5.And how about the shipping ways?
Ro-ro ship, bulk ship, or as your requested.

6.How about the delivery times?
It will takes about 7-30 days, depends on your products requests.

7.How do we start a order?
We should sign the contract and 30% payment as deposit, and balance payment before delivery.

8.How long is the warranty, and any after-sales service?
The warranty will be 1 year or 10,000km, and our professionals will solve your problems at anytime.
