5000 Liters Small LPG Filling Station for Cylinder Filling
- USD 20000.30 /Unit
- 1 Unit
- 79 Unit
- 11 days
Techinical Data as follows:
| Specification | |
| Tank | |
| Overall dimensions(mm) | 3070*1620*2210 |
| Volume | 5CBM |
| Nominal diameter(mm) | 1600 |
| Thickness of shell(mm) | 10 |
| Thickness of head(mm) | 10 |
| Net weight(kg) | 2030 |
| Design pressure | 1.77Mpa |
| Work pressure | 1.61Mpa |
| Design temperature | -19~50° |
| Filling medium | Propane |
| Corrosion allowance(mm) | 1 |
| Medium density | 420kg/m3 |
| Material | Q345R |
| Service time | 20 years |
| Accessory:Safety valve, column magnetic reversible level, pressure gauge, thermometer, cut-off valve. | |
| Liquid indictor | |
| Model | UZFAL-2.5RF2640-0.50 |
| Version | Magnetic |
| Normal pressure | 2.5Mpa |
| Scope of testing | 50-2300mm |
| Precision | 2.5 |
| Safety Valve | |
| Model | A42F-2.5-80 |
| Version | Built-in |
| Normal diameter | DN80 |
| Normal pressure | 2.5Mpa |
| Opening pressure | 1.68-1.76Mpa |
| Re-seating pressure | ≥80% of opening pressure |
| Handing system | |
| Feed pip | DN80 |
| Drain pip | DN80 |
| Admission port | DN50 |
| Sewage outfall port | DN80 |
| Vent nozzle port | DN80 |
Chengli Special Automobile Co., Ltd is aprofessional manufacturer of all kinds of special truck and trailer as well as other special equipment. LPG tank is our most advantage key products which rank Top 5in China, excellent engineers and high-grade production equipment as well as stricted quality control system can ensure all the tank from us run very well with 10-20 years use life.
Our liquefied gases tank can work In low pressure at room temperature, the volume from 5cubic meters --- 100 cubic optional.If you have other speical requirement, we can customize for you.
