/Durable Chinese Tri-Axle 60 Tons Stake Semi Trailer
- USD 7000.10 /Unit
- 1 Unit
- 71 Unit
- 29 days
Our main produccts
1. Here are the specifications for your reference,
we can manufacture the trailers according to your requires or drawing.
Dimensions | |
External dimensions | 12500*2500*3400(mm) |
Inner dimension | 12350*2320*3400(mm) |
Sole plate depth | 3mm |
Max payload | 19000kg |
Rear suspension | 1000mm |
The height from plate To the top of stake | 1800mm |
frame | |
Material | 16Mn high-tensile steel |
structure | Space frame structure .heavy duty,has the characteristics of large capacity and stable structure |
Paiting | Sand blasting then one coat of primer then two synthetic enamel finish paint |
Running system | |
Suspension system | Use the latest japanese emergency suspension system , |
Axle | Fuwa/hj/bpw |
Tire | Zhengxing tire |
Kingpin | JOST 50#/90# |
Landing gear | JOST D200 |
Brake system | |
Safe and reliable dual loop breaking air brake is used | |
2 energy-storage sub-pumps | |
The reliable relay valve is selected | |
Electrical system | Standard electrical equipment |
Accessories | |
toolbox | The big waterproof tool box that can be unloaded |
Tire carrier | Two |
others | Can be chosen by the customer |
2. Stake/Fence semi trailer photos we taken for you
3. Our workshop, welcome to have a visit!
4. Packing: Nude packing after painting wax or according to your requirement.
Shipping:By bulk cargo carrier or in container, according to the trailer dimension
Basic Info Model NO. Stake Semi Trailer Independent Suspension Type Cross Arm Type Shape Van-type Axle Number 3 Tire Number 12 Self-dumping Not Self-dumping ABS Anti-lock Braking System ABS Anti-lock Braking System Material Steel Condition New Color Red, Yellow, Green, White, Blue.etc Driver Seat Air Suspension Seat Fuel Tank 400L, 600L, 1000L Usage for Vegetable or Animaltransporting Warranty 12 Months or 100000km, According Which Comes First Trademark SINOTRUK Transport Package Nude Packing After Painted Wax Specification 12500*2500*3400 Origin China HS Code 87163990 Product Description Customer Question & Answer Ask something for more details (0) Durable Chinese Tri-axle 60 Tons Stake Semi Trailer for sale
Our main produccts
1. Here are the specifications for your reference,
we can manufacture the trailers according to your requires or drawing.Dimensions
External dimensions
12500*2500*3400(mm)
Inner dimension
12350*2320*3400(mm)
Sole plate depth
3mm
Max payload
19000kg
Rear suspension
1000mm
The height from plate
To the top of stake
1800mm
frame
Material
16Mn high-tensile steel
structure
Space frame structure .heavy duty,has the characteristics of large capacity and stable structure
Paiting
Sand blasting then one coat of primer then two synthetic enamel finish paint
Running system
Suspension system
Use the latest japanese emergency suspension system ,
also leaf spring system and air suspension system are for option
Axle
Fuwa/hj/bpw
Tire
Zhengxing tire
Kingpin
JOST 50#/90#
Landing gear
JOST D200
Brake system
Safe and reliable dual loop breaking air brake is used
2 energy-storage sub-pumps
The reliable relay valve is selected
Electrical system
Standard electrical equipment
Accessories
toolbox
The big waterproof tool box that can be unloaded
Tire carrier
Two
others
Can be chosen by the customer
2. Stake/Fence semi trailer photos we taken for you
3. Our workshop, welcome to have a visit!
4. Packing: Nude packing after painting wax or according to your requirement.Shipping:By bulk cargo carrier or in container, according to the trailer dimension
Dimensions
External dimensions
12500*2500*3400(mm)
Inner dimension
12350*2320*3400(mm)
Sole plate depth
3mm
Max payload
19000kg
Rear suspension
1000mm
The height from plate
To the top of stake
1800mm
frame
Material
16Mn high-tensile steel
structure
Space frame structure .heavy duty,has the characteristics of large capacity and stable structure
Paiting
Sand blasting then one coat of primer then two synthetic enamel finish paint
Running system
Suspension system
Use the latest japanese emergency suspension system ,
also leaf spring system and air suspension system are for option
Axle
Fuwa/hj/bpw
Tire
Zhengxing tire
Kingpin
JOST 50#/90#
Landing gear
JOST D200
Brake system
Safe and reliable dual loop breaking air brake is used
2 energy-storage sub-pumps
The reliable relay valve is selected
Electrical system
Standard electrical equipment
Accessories
toolbox
The big waterproof tool box that can be unloaded
Tire carrier
Two
others
Can be chosen by the customer
China Truck International Ltd. Is a refitted truck base of CNHTC in Jinan integrating R&D, production and sales of various special-purpose vehicles.
Jinan Special Vehicle company predecessor-Jinan Garden Machinery Works was the domestic largest manufacturer of sprinklers at the earliest time, and was incorporated into CNHTC in 2005, removed to CNHTC Zhangqiu Industrial Park in 2007 and renamed as CNHTC Jinan Special-purpose Vehicle Co., Ltd. In 2007, and removed to the new factory at No. 17668, Panwang Road, Zhangqiu, Jinan in November 2010. The new factory covers an area of 360mu and a building area of 42, 000m2, and has 360 sets of various advanced equipment, and a staff of over 600 people including more than 60 professionals. Now, the company can yield 7, 000 dumpers and van vehicles and 3000 tank trucks annually, and will realize an annual production capacity of 15, 000 refitted vehicles in 2012.
-
