/FAW 8X4 Cement Mixer Concrete Mixing Truck
- USD 40000.45 /Unit
- 1 Unit
- 21 Unit
- 26 days
Product Description
1.Description:
This series has different capacity from 8-12m³ .As to the whole truck, we use second-class Chinese and international chassis to refit, such as Faw Group, Dongfeng, Sino Truck, UD Nissan, Auman, Isuzu etc.
Chassis has such merits: High-power, Lighten weight, Nice performance.
The tank body is designed by means of three-dimensional aid design method with the characteristics of reasonable structure, large effective capacity.
We use OEM fittings, makes the tanker solid and durable, and reduce the cost to operate and maintain.
Other key parts of this transit concrete mixer include hydraulic system and mixing system.
Hydraulic system can be equipped with oil pump and motor from either German Rexroth or Italy ARK, thus offering reliable performance. The decelerator acquired from Italy PMP or Italy TOPUNIOn offers ahigh
Reduction ration of 100-130. The mixer is able to offer aminimum charging speed of 3m³ /min, and aminimum discharging speed of 2m³ /min. This ensures high mixing efficiency.
2.Merits:
1. Drum use two cove floating type spiral blades, the discharging spiral angle rotates 75° ,and reducing to 60° Upto the pyramis at bottom of drum. This unique design greatly reducing the residual discharging ratio,
Almost zero. Inclination is between 12-15° ,improving the high mixing efficiency. Also reduce the concrete impact which offers more resistance to extend the service life. The scraper plate which fitted at rear of the spiral blade ensure an assistance movement for better mixing.
2.350L large capacity water tank, compressed air form, high pressure and strong impulse to meet almost cleaning conditions.
3.Detailed Parameters:
Product Model: HZZ5250GJBJF
Chassis Model: CA1252P2K2T1S2E
Kerb Weight: 11320kgs
Max. Wheelbase: 3600+1350mm
Tire: 11.00-20 16PR
Mixing Volume: 8/9/10cbm
Geometric volume: 14.6/15.1/16.2cbm
Padding rate: 63%
Charging Speed: 3m³ /min
Discharging Speed: 2m³ /min
Residual Rate: 1%
Speed of agitator: 0-12 r/min
Gradient: 13-15 °
Concrete slump: 70-260mm
Water supply: Air compressed air
Yourarealwayswelcometovisitourfactoryatanytime
5.FAQ
Basic Info Model NO. FAW 8x4 Drive Mode 6x4 Maximum Horsepower 300-400hp Condition New Color Red Yellow Green White Black Blue Driver Seat Air Suspension Seat Warranty One Year or 100000km Which Comes First Trademark FAW Transport Package Nude Packing Specification CCC, ISO9001 Origin China HS Code 8705400000 Product Description Customer Question & Answer Ask something for more details (0) 1.Description:
This series has different capacity from 8-12m³ .As to the whole truck, we use second-class Chinese and international chassis to refit, such as Faw Group, Dongfeng, Sino Truck, UD Nissan, Auman, Isuzu etc.
Chassis has such merits: High-power, Lighten weight, Nice performance.
The tank body is designed by means of three-dimensional aid design method with the characteristics of reasonable structure, large effective capacity.
We use OEM fittings, makes the tanker solid and durable, and reduce the cost to operate and maintain.
Other key parts of this transit concrete mixer include hydraulic system and mixing system.
Hydraulic system can be equipped with oil pump and motor from either German Rexroth or Italy ARK, thus offering reliable performance. The decelerator acquired from Italy PMP or Italy TOPUNIOn offers ahigh
Reduction ration of 100-130. The mixer is able to offer aminimum charging speed of 3m³ /min, and aminimum discharging speed of 2m³ /min. This ensures high mixing efficiency.
2.Merits:
1. Drum use two cove floating type spiral blades, the discharging spiral angle rotates 75° ,and reducing to 60° Upto the pyramis at bottom of drum. This unique design greatly reducing the residual discharging ratio,
Almost zero. Inclination is between 12-15° ,improving the high mixing efficiency. Also reduce the concrete impact which offers more resistance to extend the service life. The scraper plate which fitted at rear of the spiral blade ensure an assistance movement for better mixing.
2.350L large capacity water tank, compressed air form, high pressure and strong impulse to meet almost cleaning conditions.
3.Detailed Parameters:
Product Model: HZZ5250GJBJF
Chassis Model: CA1252P2K2T1S2E
Kerb Weight: 11320kgs
Max. Wheelbase: 3600+1350mm
Tire: 11.00-20 16PR
Mixing Volume: 8/9/10cbm
Geometric volume: 14.6/15.1/16.2cbm
Padding rate: 63%
Charging Speed: 3m³ /min
Discharging Speed: 2m³ /min
Residual Rate: 1%
Speed of agitator: 0-12 r/min
Gradient: 13-15 °
Concrete slump: 70-260mm
Water supply: Air compressed air
Yourarealwayswelcometovisitourfactoryatanytime
5.FAQ
| Q1:I don't want this configuration |
| A: The configuration can be changed according to your needs |
| Q2: Minimum order quantity? |
| A: MOQ is 1unit. |
| Q3: Productionperiod? |
| A:(Truck & trailer)Within 30days since the moment we got your down payment (Parts) Within 7 days since the moment we got your down payment |
| Q4: Payment term? |
| A: (Truck & trailer)30%T/T as deposit, the balance should be paid before delivery. or L/C (Parts) 100%T/T should be paid before delivery |
| Q5: Shipping? |
| A:(Truck & trailer) by container or RoRo/Bulk shipment. (South America,Middle East, Africa, Oceania etc.) by road or railway.(Russia, Mongolia, Kazakhstan, Uzbekistan ,Vietnam, Laos etc.) (Parts) by international courier service, such asDHL, TNT, UPS, or Fedex.The goods above $1000 can be shipped by sea |
| Q6: Can you supply some quick-wear truck or semi trailer parts ? |
| A: Yes, we can supply truck and semi trailer parts as your request,such as oil filter, fuel filter, air filter, traction, traction pin, balance beam and semi-trailer plate spring, hanging accessories, turntable, all kinds of trailer brake pads, brake pan, bearings etc. |
Basic Info Model NO. FAW 8x4 Drive Mode 6x4 Maximum Horsepower 300-400hp Condition New Color Red Yellow Green White Black Blue Driver Seat Air Suspension Seat Warranty One Year or 100000km Which Comes First Trademark FAW Transport Package Nude Packing Specification CCC, ISO9001 Origin China HS Code 8705400000 Product Description Customer Question & Answer Ask something for more details (0) 1.Description:
This series has different capacity from 8-12m³ .As to the whole truck, we use second-class Chinese and international chassis to refit, such as Faw Group, Dongfeng, Sino Truck, UD Nissan, Auman, Isuzu etc.
Chassis has such merits: High-power, Lighten weight, Nice performance.
The tank body is designed by means of three-dimensional aid design method with the characteristics of reasonable structure, large effective capacity.
We use OEM fittings, makes the tanker solid and durable, and reduce the cost to operate and maintain.
Other key parts of this transit concrete mixer include hydraulic system and mixing system.
Hydraulic system can be equipped with oil pump and motor from either German Rexroth or Italy ARK, thus offering reliable performance. The decelerator acquired from Italy PMP or Italy TOPUNIOn offers ahigh
Reduction ration of 100-130. The mixer is able to offer aminimum charging speed of 3m³ /min, and aminimum discharging speed of 2m³ /min. This ensures high mixing efficiency.
2.Merits:
1. Drum use two cove floating type spiral blades, the discharging spiral angle rotates 75° ,and reducing to 60° Upto the pyramis at bottom of drum. This unique design greatly reducing the residual discharging ratio,
Almost zero. Inclination is between 12-15° ,improving the high mixing efficiency. Also reduce the concrete impact which offers more resistance to extend the service life. The scraper plate which fitted at rear of the spiral blade ensure an assistance movement for better mixing.
2.350L large capacity water tank, compressed air form, high pressure and strong impulse to meet almost cleaning conditions.
3.Detailed Parameters:
Product Model: HZZ5250GJBJF
Chassis Model: CA1252P2K2T1S2E
Kerb Weight: 11320kgs
Max. Wheelbase: 3600+1350mm
Tire: 11.00-20 16PR
Mixing Volume: 8/9/10cbm
Geometric volume: 14.6/15.1/16.2cbm
Padding rate: 63%
Charging Speed: 3m³ /min
Discharging Speed: 2m³ /min
Residual Rate: 1%
Speed of agitator: 0-12 r/min
Gradient: 13-15 °
Concrete slump: 70-260mm
Water supply: Air compressed air
Yourarealwayswelcometovisitourfactoryatanytime
5.FAQ
| Q1:I don't want this configuration |
| A: The configuration can be changed according to your needs |
| Q2: Minimum order quantity? |
| A: MOQ is 1unit. |
| Q3: Productionperiod? |
| A:(Truck & trailer)Within 30days since the moment we got your down payment (Parts) Within 7 days since the moment we got your down payment |
| Q4: Payment term? |
| A: (Truck & trailer)30%T/T as deposit, the balance should be paid before delivery. or L/C (Parts) 100%T/T should be paid before delivery |
| Q5: Shipping? |
| A:(Truck & trailer) by container or RoRo/Bulk shipment. (South America,Middle East, Africa, Oceania etc.) by road or railway.(Russia, Mongolia, Kazakhstan, Uzbekistan ,Vietnam, Laos etc.) (Parts) by international courier service, such asDHL, TNT, UPS, or Fedex.The goods above $1000 can be shipped by sea |
| Q6: Can you supply some quick-wear truck or semi trailer parts ? |
| A: Yes, we can supply truck and semi trailer parts as your request,such as oil filter, fuel filter, air filter, traction, traction pin, balance beam and semi-trailer plate spring, hanging accessories, turntable, all kinds of trailer brake pads, brake pan, bearings etc. |
Product Images
Factory Show
China Truck International Ltd. Is a refitted truck base of CNHTC in Jinan integrating R&D, production and sales of various special-purpose vehicles.
Jinan Special Vehicle company predecessor-Jinan Garden Machinery Works was the domestic largest manufacturer of sprinklers at the earliest time, and was incorporated into CNHTC in 2005, removed to CNHTC Zhangqiu Industrial Park in 2007 and renamed as CNHTC Jinan Special-purpose Vehicle Co., Ltd. In 2007, and removed to the new factory at No. 17668, Panwang Road, Zhangqiu, Jinan in November 2010. The new factory covers an area of 360mu and a building area of 42, 000m2, and has 360 sets of various advanced equipment, and a staff of over 600 people including more than 60 professionals. Now, the company can yield 7, 000 dumpers and van vehicles and 3000 tank trucks annually, and will realize an annual production capacity of 15, 000 refitted vehicles in 2012.
