H2000 Series16t Heli Diesel Forklift (CPCD160)

Heli Forklift is No 1 for 22 consecutive years already

Application:
This series forklift trucks are widely used in stations, ports, airports, warehouse and other places for loading, unloading and short distance transporting of the packaged goods.

Main Features:
Cummins Diesel engine, comply to EPA standards on None-road application, with genuine attached parts to guarantee the normal use and maintainance.

ZF Transmission system. This transmission system integrated various control software in one controller, easy to handle. It can also be diagnosed easily with the diagnostic machine interface.

Kessler Front Axle. This Axle has high load capacity and brake torque to be safe and reliable enough. Wet type brake is water-resistant and dust-resistant and maintenance free.

Rexroth Main Hydraulic system. Using hydraulic oil pressure feedback various pump system to realize the continuous oil supplying and reduce the overflow losses and increase the effiency to save the energy and reduce the oil temperature.

Using prior-steering strategy Pre-open valve on Multi-control Valve to separate the operation level and control vavel to realize remote control. It can be operated with comfort and safety and release the tension of the driver.

Model Technical data:

Model		CPCD140-Cu	CPCD150-Cu	CPCD160-Cu	CPCD160-Cu(1200)	CPCD180-Cu
Power type		Diesel
Load capacity	kg	14000	15000	16000	16000	18000
Load center	mm	900			1200
Lifting height	mm	3000				4000
Overall length(with forks)	mm	7250			8380
Overall width	mm	2560
Overall height(top of mast)	mm	3300				3800
Min. turning radius	mm	4970			5600
Max. travel speed(without load)	Km/h	30
Service weight	kg	22500	23000	23500	24700	25700

-------------------
