40t Standard Diesel Hand Hydraulic Forklift Hh40-N4-D

Generals

Model

Unit

HH40Z

Power type

Diesel

Rated capacity

Kg

4000

Load center

mm

500

Dimensions

Lift height

mm

3000

Free lift height

mm

150

Fork size (L× W× T)

mm

1070× 150× 55

Mast inclination F/R

Deg

6° /12°

Front overhang

mm

562

Overall Dimensions

Length to face of fork

mm

3091

Overall width

mm

1485

Mast lowered height

mm

2380

Overhead guard height

mm

2290

Turning radius

mm

3370

Min. right angle aisle width

mm

3755

Performance

Travel speed

Unload I/II

Km/h

13/12

Full load I/II

Km/h

32/26

Lift speed

mm/s

600/400

Max. grade ability

%

20

Max. drawbar pull

Kn

21

Self weight

Kg

6450

Wheels &Tires

Tires

Front

28x9-15-12PR

Rear

7.00-12-12PR

Tread

Front Q

mm

1180

Rear S

mm

1100

Wheelbase

mm

2250

Min. ground clearance
(unload/full load)

Mast

mm

175/145

frame

mm

190/180

Drive units &Control

Battery

V/Ah

2-12V/90AH

Engine

Model

R4105G32

Rated output

Kw/rpm

59/2300

Rated torque

N. m/rpm

280/1600-1800

Displacement

cc

4156

Transmission

Type

Hydraulic

Shift Fwd/Rwd

2/1

Operating pressure

Mpa

17
