XCMG 3m Width Asphalt Road Paver RP756

XCMG Asphalt concrete cement paver RP756 on Sale!!!


RP756 is a kind of new generation multifunctional paver. It is completely upgraded with new technology, featuring excellent performance, simple operation, and superior performance/price ratio. With the max. paving width of 7.5m, it is the optimal equipment for paving various kinds of materials for the construction of highways. The conveying system and material distribution system have extra large capacity and they are independently driven (from left/right), which can meet different construction requirements. In addition, it is more to operate and it can achieve optimal paving effect under the most tough work environment.

Items	Unit	Parameters
Basic paving width	m	3
Max. paving width	m	7.5
Max. paving thickness	mm	350
Paving speed	m/min	0~18
Travel speed	km/h	0~3.0
Theoretical Productivity	t/h	600
Hopper Capacity	t	14
Gradeability	%	20
Pavement evenness	mm/3m	3
Transverse levelling accuracy	%	±0.03
Centre crown ratio	%	-1~3
Engine model		D6114ZG1B
Engine power	kw	140
Engine speed	r/min	2300
Fuel tank capacity	L	270
Machine weight	t	19.9~24.6
Dimension	mm	6700×3000×3850
Vibration frequency (optional)	Hz	0~50
Screed heating		Gas heating
Auger and conveyor control		Automatic Control by Ultrasonic Sensors
Automatic levelling control		Simulation control

Items	Unit
Screed model	575(RP802)
Type	Double vibrator, gas heating
Extension	Mechanical assembly
Width	0-1470r/min
Vibrator speed	3,5,7,9mm
Main amplitude
Auxiliary amplitude	0,3,6,9,12mm
