XCMG 6m Width Asphalt Concrete Paver RP601L

XCMG Asphalt Concrete Cement Paver RP601L

RP601L is a tyre type paver featuring good maneuverability, high speed and large traction force. It can meet different paving requirements, and the paving width can be stepless adjusted from 2.5m to 7.0m. It is mainly used for the maintenance of municipal roads, parking lots, highways of high grade and road paving operations. It can be used to pave multiple kinds of materials, especially the asphalt concrete materials, and it can be flexibly used in small, medium or large paving operations. And it also features satisfactory levelness and compactness.

Items	Unit	Parameters
Basic paving width	m	2.5
Max. paving width	m	6.0/7.0
Max. paving thickness	mm	300
Paving speed	m/min	0~18
Travel speed	km/h	0~18
Theoretical Productivity	t/h	400
Hopper Capacity	t	13
Gradeability	%	20
Pavement evenness	mm/3m	3
Transverse levelling accuracy	%	±0.03
Centre crown ratio	%	0~+3
Engine model		D4114ZG2B
Engine power	kw	100
Engine speed	r/min	2400
Fuel tank capacity	L	170
Machine weight	t	15.3~19
Dimension	mm	6096X2580x3832
Auger speed	r/min	0~82
Conveyor speed	m/min	0~36
Vibrator speed	r/min	0~1470
Vibrator amplitude	mm	4
Screed heating		Electrical heating
Auger and conveyor control		Automatic Control by Ultrasonic Sensors
Automatic levelling control		Simulation control

Items	Unit	Parameters
Screed model	/	475
Type	/	Gas heating, vibration
Extension	/	Hydraulic
Width	m	2.5-6.0/7.0m
Vibrator speed	rpm	0-1470
