80m Yuchai Drilling Machine Ycr260 Rotary Drilling Rig

FOB Price: USD 89000.00 /Unit
Min.Order: 1 Unit
Supply Ability: 42 Unit
Delivery time： 7 days

Product Description

80m YUCHAI drilling machine YCR260 Rotary Drilling Rig
Contact way:
Sales Manager
Alisa Wang

Newindu E-Commerce (Shanghai) Co.,Ltd.
Add: Suite 1326, Fortune Times Tower, No. 1438 North Shanxi Road, Shanghai, China
Tel: +86-21-62770109Fax: +86-21-62120109
Mobile +86-18616224775

Alibaba Website: https://cnnewindu.en.alibaba.com/

Product description:

80m YUCHAI drilling machine YCR260 Rotary Drilling Rig

Project		Parameters
Chassis	Engine Type	QSM11-C330
	Engine Power/Speed	246/2100
	Crawler Expansion Width (From The Outside)	4400
	Crawler Board Width	800
	Traction Force	520
Power Head	Max. Output Torque	260
	Power Head Speed	6-25
	Max.Pull-Down Piston Push	200
	Max.Pull-Down Piston Pull	250
	Pressurized cylinder Stroke	5000
Winch	Main Winch
	Max.Line Pull of the first layer	280
	Max.Line Speed	55
	Wire Rope Diameter	32
	Auxiliary Winch
	Max.Line Pull of the first layer	80
	Max.Line Speed	65
	Wire Rope Diameter	20
Mast	Mast Forward Inclination	5
Mast	Mast Sideward Inclination	4
Hydraulic Pump	Max. Working Pressure	35
Depth and Diameter	Max. Drilling Diameter	2500
Depth and Diameter	Max. Drilling Depth	80
Drilling Pipe	Drilling Pipe	508
Drilling Pipe	Working State Quality	82

Product image:
80m Yuchai Drilling Machine Ycr260 Rotary Drilling Rig

Product Images

80m Yuchai Drilling Machine Ycr260 Rotary Drilling Rig Images 1
