Top Sale XCMG Xr220d Rotary Drilling Rig Price

XCMG official manufacturer XR220D CFA Rotary Drilling Rig

Feature

• Adopt single rope main winch, effectively solving the wear problem of the steel wire rope and improving its service life.
• Install the infrared camera, which can observe the service condition of the main winch steel wirerope in the cab day and night.
• Many configurations can be installed according to the customers' requirements (such as: landing leg cylinder, automatic slew).
• Adopt imported Cummins electronic control turbocharging engine, meeting the Europe III emission standard. It is energy-efficient and environmental friendly, and has strong power.
• The hydraulic system adopts limiting power control and positive flow control, which improves the efficiency of the hydraulic system and saves more energy.
• The patent parallelogram variable structure realizes the large-scope working area. The mast is designed to be the box-type structure, which has high intensity and rigidity, effectively ensuring the drilling preciseness.
• It can be attached with 5 drill rods. The maximum drilling depth can reach 67.5m.

Main Technical Specification
Engine	Model		CUMMINS QSL-325
	Rated Power	kW	242
Rotary Drive	Max. output torque	kN·m	220
	Rotary speed	r/min	7~22
Max. Drilling Diameter		mm	ø2000
Max. Drilling Depth		m	67,80
Pull-Down Cylinder	Max.pull-down piston push	kN	200
	Max.pull-down piston pull	kN	200
	Max.pull-down piston stroke	m	5
Crowd Winch	Max.pull-down piston push	kN	200
	Max.pull-down piston pull	kN	210
	Max.pull-down piston stroke	m	15
Main Winch	Max.Pulling force	kN	230
	Max.line speed	m/min	70
Auxiliary Winch	Max.Pulling force	kN	80
	Max.line speed	m/min	60
Mast Rake	Side/forwards/backwards		±4°/5°/15°
Undercarrige	Max. traveling speed	km/h	1.5
	Max.grade ability	%	35
	Min. Clearance	mm	468
	Track shoe width	mm	800
	Distance between tracks	mm	3500~400
Hydraulic System	Working pressure	Mpa	35
Overall Drilling Weight		t	70
Dimension	Working condition	mm	10260x4400X22120
	Transportation condition	mm	16355X3500x3510
