New 52m Mobile Mounted Concrete Boom Pump Truck Hb52 with Cheap Price

FOB Price: USD 187000.28 /Unit
Min.Order: 1 Unit
Supply Ability: 34 Unit
Delivery time： 22 days

Product Description

NEW 52m Mobile Mounted Concrete Boom Pump Truck HB52 with cheap price
Features:

HB52 concrete pump is the medium size machine, and widely applied in high buildings and large foundation equipments of bridge, power plant, steel plant, water treatment plant. The machine features environmental care, safety, reliability and advanced

Contact way:
Sales Manager
April Chen
Newindu E-Commerce(Shanghai)Co.,Ltd.
Add:Suit 1326, Fortune Times Tower, No. 1438 North Shanxi Road, China
Mobile:+86-135 8550 0864
Web:http://www.evangelchina.com

Parameters:

Travel
Category	Item	Unit	Parameter
Chassis	Model		FM440
	Manufacturer		VOL
	Max. speed	km/h	90
	Min. turning diameter	m	27.4
	Brake distance	m	≤10
	Wheelbase	mm	1995+5205+1370+1450
	Tread (front/rear)	mm	2028/1872
	Approach angle/departure angle	.	18/12
	Min. clearance	mm	270
	Tyre specification		12.00R20
Engine	Model		D13
	Displacement	l	12.8
	Emission Standard		Nation III GBIII
Others	Dimension (Length×Width×Height)	mm	14665×2500×3990
	Total vehicle weight	kg	47000
	Fuel tank capacity	l	410
	Fuel consumption per 100km	l/100km	50
Pumping operation
Pumping system	Theoretical output(high pressure/low pressure)	m3/h	90/138
	Concrete pumping pressure(high pressure/low pressure)	Mpa	13/8.7
	Theoretical pumping times(high pressure/low pressure)	/min	18/27
	Max. diameter of pumping concrete aggregate		40
	Feeding height		1450
Placing boom	Pumping slump range		12-23
	Reach height		51.5
	Reach depth		40
	Slewing radius		47.5
	Slewing angle		364
	1st boom stretch angle		96
	2nd boom stretch angle		180
	3rd boom stretch angle		180
	4th boom stretch angle		180
	5th boom stretch angle		260
