Portable 52m Concrete Pump Hb52 Good Price Concrete Pump Parts

portable 52m concrete pump HB52 good price concrete pump parts

Contact way:
Sales Manager
Alisa Wang

Newindu E-Commerce (Shanghai) Co.,Ltd.
Add: Suite 1326, Fortune Times Tower, No. 1438 North Shanxi Road, Shanghai, China
Tel: +86-21-62770109Fax: +86-21-62120109
Mobile :+86-18616224775

Product description:
portable 52m concrete pump HB52 good price concrete pump parts

Travel
Category	Item	Unit	Parameter
Chassis	Model		FM440
	Manufacturer		VOLVO
	Max. speed	km/h	90
	Max. gradeability		38%
	Min. turning diameter	m	27.4
	Brake distance	m	≤10
	Wheelbase	mm	1995+5205+1370+1450
	Tread (front/rear)	mm	2028/1872
	Approach angle/departure angle	.	18/12
	Min. clearance	mm	270
	Tyre specification		12.00R20
Engine	Model		D13
	Output power	kw/(r/min)	324/1400~1800
	Max. torque	N.m/(r/min)	2200/1050~1400
	Displacement	l	12.8
	Emission Standard		Nation III GB
Others	Dimension (Length×Width×Height)	mm	14665×2500×3990
	Total vehicle weight	kg	47000
	Fuel tank capacity	l	410
	Fuel consumption per 100km	l/100km	50
Pumping operation
Pumping system	Theoretical output(high pressure/low pressure)	m³/h	90/138
	Concrete pumping pressure(high pressure/low pressure)	Mpa	13/8.7
	Theoretical pumping times(high pressure/low pressure)	Times/min	18/27
	Max. diameter of pumping concrete aggregate		40
	Feeding height		1450
Placing boom	Pumping slump range		12-23
	Reach height		51.5
	Reach depth		40
	Slewing radius		47.5
	Slewing angle		364
	1st boom stretch angle		96
	2nd boom stretch angle		180
	3rd boom stretch angle		180
	4th boom stretch angle		180
	5th boom stretch angle		260
	Outrigger spanOverall outrigger span		11020±50
	Front outrigger transverse span		10730±50
	Rear outrigger transverse span		10430±50
Others	Dosing type		S valve
	Lubricating method		Automatic lubrication
	Controlling method		Manual/remote control
	Water tank capacity		650
	Max. pressure of water pump		2

Product image:
