New Cheap Concrete Mixer with Pump Truck Machine Syg5360thb 43

New cheap Concrete Mixer with Pump Truck Machine SYG5360THB 43

Feature

One Button Stabilization Technology

The one button stabilization technology quickly dampens any boom movement resulting from repositioning the boom. This allows precise positioning of the end hose.

Boom Anti Vibration Technology

The boom anti vibration technology reduces vibration during pumping by 50% allowing less movement and greater control of the end hose.

Parameters
Length
12500 mm
Width
2500 mm
Height
4000 mm
Empty weight
36350 kg
Boom & Outrigger
Vertical reach
43.3 m
Horizontal reach
38.3 m
Reach depth
25.5 m
Unfolding reach
13.9 m
1st section-Length
9760 mm
1st section-Articulation
89°
2nd section-Length
7670 mm
2nd section-Articulation
180°
3rd section-Length
7410 mm
3rd section-Articulation
180°
4th section-Length
7315 mm
4th section-Articulation
235°
5th section-Length
7110 mm
5th section-Articulation
215°
Rotation
±360°
Outrigger spread L-R-Front
9300 mm
Outrigger spread L-R-Rear
9620 mm
Pumping System
Output (Low/High-pressure)
170/120 m³/h
Pressure (Low/High-pressure)
8.3/12 Mpa
Max. strokes per minute (Low/High-pressure)
29/19 times/min
Delivery cylinder diameter
260 mm
Stroke length
1900 mm
Hydraulic system
Open
Hydraulic system pressure
32 Mpa
Hydraulic tank capacity
680 L
Water tank capacity
620 L
Pipe size
125 mm
End hose length
3 m
End hose diameter
125 mm
Chassis
Chassis model
BENZ Actros 4141
Engine model
OM501LA./3
Engine power
300/1800 kW/rpm
Emissions
Tier / Tier III
Fuel tank capacity
400 L
Displacement
11.946 L
