Description:

XS142J/XS162J/XS182Jvibratorycompactorisakindofheavydutyself-propelledvibratorycompactor.Itcaneffectivelycompactvarioussoillayersandrockfill,andcanbeappliedtotheconstructionsofmodernfreeways,airports,embankmentfill,ports,dams,railways,mines,etc.
Performancefeature
Thespaciousandbrightcabfeatureswideviewandcomfort.
Simpleoperation
Thehumanityinstrumentpanelhasareasonablelayout,allthecontrolbuttonsareclearataglance.
Adoptthegearboxwithsynchronizer,whichiseasytooperate.
Thespecialcompactordriveaxlehasthefunctionofpreventingslipping,featuringstrongtraction.
Reliableanddurablehydraulicsystem
Thestandardconfigurationincludesimportedopengearpumpandmotor.Theoptionalconfigurationincludesclosedhydraulicvibrationsystem,importedpistonpump,motor(16t,18t).Allthosehavealongservicelife,supplyingstablestart-oscillationandoscillationstopandhighcompactingquality.
Energy-savingandenvironmentalfriendlypower
ShanghaiDieselEngine114serieswater-cooledenginehaslownoise,meetingtheemissionstandardofEuropeanI.Themaintenance-freebatterycanbestartedeasilyandworksmoothlyinlowtemperature.
Highefficientandreliablevibratorycompactingsystem
Uniquedrumstructurefeaturesgoodrigidityandintensity.Thebearingadoptsshortcylindricalbearing,featuringhighrotaryspeedlimitandstrongbearingcapacity.Theleftvibrationchamberandrightvibrationchamberaresymmetrical,avoidingthepolarizationofthedrum.
Thevibratorybearingcanbelubricatedwhenthecompactortravels,whichissimpleandconvenient,ensuringaquitelowlubricatingsystemfailurerate.
Adoptthenumericalcontrolblanking,numericalcontrolplaterolling,numericalcontrolbender,andnumericalcontrolhorizontalmachiningcentertoensuretheprecisionofthewholemachining.
Optionalconfiguration
Theintegralconvexblockdrum,splitconvexblockdrum,andthecabwithairconditioning.
Convenientmaintenance
Theenginecoveriseasytoopen,andtheopeningangleislarge,whichmakethemaintenancepartaccessible.
Thehighpositionedairintakeprolongsthemaintenanceintervaloftheairfilter

Technical Paramters

Model	Unit	XS142J
Operatingweight	kg	14000
Weightonfrontdrum	kg	7000
Staticlinearpressure	N/cm	322
Speedrange	km/h
SpeedI		2.7
SpeedII		4.8
SpeedIII		10.5
Theoreticalgradeability	%	30
Min.externalturningradius	mm	6800
Steeringangle	°	±30
Oscillatingangle	°	±11
Vibrationfrequency	Hz	28
Nominalamplitude(high/low)	mm	1.9/0.95
Excitationforce(high/lowamplitude)	kN	274/137
Enginemodel		SC5D125G2B1
Type	Watercooled,pressurized	Watercooled,pressurized
Max.power	kW	92@2200r/min
Engineoilconsumption	g/kW.h	230
Hydraulicoiltankcapacity	L	170
Fueltankcapacity	L	180
