Low price medium road cold milling machinery XM130K
Feature
(1) Hydraulic driving milling drum has the obvious characteristics of stable milling and high efficiency.
(2) Compact three-wheeled machine with front-wheel drive .The advance speed is infinitely variable in both gear which can be suitable for the requirement of different working conditions.
(3) The front steering driving axie has large steering angle and small turming radius ,can mill along the manhole covers.
(4) The high-strength and high wear resistance imported cutter head and cutter rest have long service life and low construction cost.
(5) The imported hydraulic elements have high working reliability.
(6) Excellent welting milling performance with right rear leg which can be fast swung into the frame makes the milling drum attached to the road edge stone or wall for milling operation.
(7) Handheld breakers and rumble strip equipment can be selected.
Parameters
MODEL | Unit | XM130K | |
Engine model | 6CTA8.3-C260 | ||
Rated power /speed | Kw/rpm | 194/2100 | |
Performance parameters | Operating speed | m/min | 0-30 |
Travel speed | Km/h | 0-7 | |
Gradeability | % | 50 | |
Ground clearance | mm | ≤200 | |
Operating weight | Kg | 200 | |
Operating parameters | Max.milling and mixing width | mm | 1320 |
Max.milling and mixing depth | mm | 315 | |
Number of tools | 112 | ||
Milling drum diameter | mm | 980 | |
complete dimension(L*W*H) | mm | 5255*2480*3245 | |
dimensions | Conveyor(L*W*H) | mm | 7020*1030*900 |
Fuel tank | L | 280 | |
Hydraulic oil tank | L | 160 | |
Water tank | L | 780 |
