Lutong 12 Ton Vibratory Single Drum Roller Lt212

Lutong 12 Ton Vibratory Single Drum Roller Lt212

Dimension:5640x2258x2970mm
Packing method:40HQ container
Best delivery:In 10days after deposit
Payment terms:T/T or L/C

LT220B,LT218B,LT216B,LT214,LT212,LT210 eavy duty vibratory rollers effect powerful centrifuga force and great static linear load, They are suitable for non-cohesive materials, such as sandy soil,gravel,crushed stones, rock fillings and slightly cohesive soils, designed for large foundation constructions such as high-class highways, mines, dams, airports, harbors, railways and industrial areas etc.
Main Features
Mechanical travel drive, double amplitude, hydraulic vibration and steering with optimal function/price ratio and reliable performance.
Reliable D6114 or YC6108 diesel engine for convenient operation and maintenance.
Two sets of brake devices, a hand brake and foot pedal brake, assure the machine's safety and dependability.
Spacious and comfortable cab mounted on top quality rubber damping elements.
World advanced technology is adopted for the hydraulic vibration technology, high in reliability, simple and convenient in maintenance, and low in cost.
Equipped with padfoot or removal padfoot as option.

MODEL		LT212
Operating mass	Kg	12000
Static linear load	N/cm	276
Vibrating amplitude	Mm	1.8/0.9
Vibrating frequency	Hz	30
Centrifugal force	KN	270/140
Travel speed
1 st gear		1.8
2 nd gear		3.7
3 rd gear		9.7
Grade ability	%	35
Turning angle	.	35
Overall dimension	mm	5640x2258x2970
Ground clearance	mm	360
Vibration drum width	mm	2100
Drum diameter	mm	1400
Drum rim thickness	mm	24
Wheelbase	mm	3080
Groud clearance	mm	360
Diesel model		YC6108G
Diesel power	Kw	85
Turning radius	mm	7000
Fuel tank capacity	L	180
Electrical voltage	V	24
Hydraulic tank capacity	L	150
Diesel speed	r/min	2000
Type size		17.5-25
Vertical oascillation	°	8

-------------------
