/3 Axle 75ton Semi Trailer
- USD 36500.00 /Unit
- 1 Unit
- 12 Unit
- 15 days
Product Description
3 Axle 70T Lowbed Semi-trailer Technical Specification
| Vehicle | ||
| Vehicle Name | 3 axle low bed semi-trailer | |
| Vehicle Model | 9400TDP | |
| Loading capacity | 70T | |
| Dimension Parameter | ||
| Overall length(mm) | 12000 | |
| Overall width(mm) | 3000 | |
| Overall height(mm) | 3150 | |
| Wheelbase (mm) | 7580+1310+1310 | |
| Front / rear suspension (mm) | -/1350 | |
| Front / rear tread (mm) | -/2050/2050/2050 | |
| Weight Parameter | ||
| GVW (kg) | 40000 | |
| Payload weight (kg) | 75T | |
| Kerb weight (kg) | 12000 | |
| Others | ||
| Spring leaf No. | -/10/10/10 | |
| Tyre type | 275/75R22.5 | |
| Tyre No. | 12 | |
| Suspension | 3 axle mechanismsuspension | |
| Axle | 3* 16T FUWA | |
| Landing gear | 28T manual operation | |
| Material of main beam | 16Mn | |
| Main beam | Height: 550mm, top flange: 20mm, bottom flange:25mm, middle flange: 12mm, flange width: 200mm | |
| Platform plate | 6mmdiamond plate | |
| Kingpin size | 2"or 3.5" | |
| Electrical | 24V, 7 pin socket | |
| Equipment | Double tyre carrier, one tool box | |
| Painting | Sand blasting before painting, one coat of primer, anti-corrosion, two coat of finish painting, color can be choosed as client request. | |
