/Heavy Duty 40m3 Dump Semi Trailer
- USD 2800.00 /Unit
- 1 Unit
- 22 Unit
- 19 days
Product Description
heavy duty 40m3 dump semi trailer
PRODUCT DEscriptION
PRODUCT IMAGE:
PRODUCT DEscriptION
| Type | Dump semi trailer |
| Top flange plate thickness | 12 mm |
| Web thickness | 6 mm |
| Bottom thickness | 12 mm |
| Structure pattern of main beam | Flat and straight beam |
| Side beam specification | 14# section steel |
| Sidewall panel height | 600mm |
| Floor type | Flat plate |
| Floor thickness | 2 mm |
| Axle specification/brand | 13TFWB |
| Axle quantity | 3 pieces |
| Tire specification/brand | 12R22.5 |
| Tire quantity | 12 pieces |
| Rim specification | 9.0-22.5 |
| Rim quantity | 12 pieces |
| Leaf spring | 10 pieces/Model 2 |
| ABS specification | 4S/2M |
| Brake chamber | Four spring loaded braking chambers, two air loaded braking chambers |
| Landing gear | 28T BAOHUA, two sides operation |
| King pin | 90mm, welded type |
| This trailer is designed as per HTS, with loading capacity 50T. Without PTO. 6 pieces lifting cylinders, plus 1 piece self-sescue cylinder. | |
