23 Ton Roller Lutong Lt623b Single Drum Vibratory Roller

LT623B Super Heavy Single Drum Vibratory Road Roller
1. LT623B road roller adopts imported hydraulic components.
2. Operating mass: 23000kg.
3. Overall dimension: 6410x2350x3090mm.

This machine is super heavy-duty vibratory roller, possesses agreat working mass and strong centrifugal force. It is the best compaction equipment of high quality and high effect in the large scale mechanized construction. This machine is suitable for non cohesive materials, such as graves, macadam, macadam aggregate mixtures and sandy soil etc. The machine is ideal equipment for expressway. Mining road, embankment, sea port and industrial sites.

Main Features
1. Mechanical drive, dual amplitude, hydraulic vibration and steering.
2.132KW Supercharged diesel engine, which comply with the operating conditions above 4000 meters altitudes.
3. Two sets of brake devices, ahand brake and foot pedal brake, assure the machine's safety and dependability.
4. Spacious and comfortable cab mounted on top quality rubber damping elements, with hydraulic upturn function to facilitate the repair and maintenance.
5. World advanced hydraulic vibration technology, high in reliability, simple and convenient in maintenance, and low in cost.
6. Vibration system adopts imported hydraulic components.
7. Removable Padfoot drums can be added as your option.

MODEL		LT623B
Operating mass	kg	23000
Static linear load	N/cm	560
Vibration amplitude	mm	1.9/0.95
Vibration frequency	Hz	30
Centrifugal force	KN	430/330
Travel speed	Km/h	10.5
Grade ability	%	30
Turning radius	mm	7500
Overall dimension	mm	6410x2350x3090
Vibration round width	mm	2100
Wheelbase	mm	3380
Diesel model		SC8D180
Diesel power	kW	132

-------------------
