Chinese 26 Ton Single Drum Road Roller Machine Xs262j Price
- USD 45000.60 /Unit
- 1 Unit
- 49 Unit
- 23 days
Chinese single drum road roller machine XS262J price
Feature
Excellent Powertrain
The six-cylinder, direct injection, water-cooled, turbocharged Shangchai D6114ZG engine that offers high power reserve, together with the electrically controlled power box and the optional drive axle with NO-SPIN function supplies stable power transmission. The power system of XS202J can play an optimal traction performance in any cases.
Outstanding Compaction
Dual vibration frequencies and dual amplitudes satisfy different jobsite requirements. imported heavy-duty piston pumps and motors form a closed circuit to provide enhanced durability and reliability, ensuring uniform compaction. Largest diameter drum and highest static linear load of its kind in china coupled with optimized drum structure and vibration parameters work together for outstanding compaction result and great productivity.
Reliable Electrical System
The electrical system adopts internationally sourced water-proof, dust-proof, vibration-resistant electric connectors for increased reliability.
imported maintenance-free battery has high start-up current and good adaptability.
All-round Safety Consideration
Independently actuated caliper disc type service brakes and band type parking brakes assure safe and reliable braking.
Ant-slip handrail and stairs allow the operator to get on and off the machine freely.
During machine transportation, an articulated locking device can be used to lock the front and rear frame for safe transportation.
High Reliability
Advanced brake and clutch protection system protect the clutch and transmission against damages caused by operation mistakes.
Parameters
| Item | Unit | XS262J |
|---|---|---|
| Operating weight | kg | 26000 |
| Weight on front drum | kg | 13000 |
| Static linear load | N/cm | 582 |
| Speed range | km/h | |
| Speed I | 2.52 | |
| Speed II | 4.95 | |
| Speed III | 8.1 | |
| Theoretical gradeability | % | 35 |
| Min. external turning radius | mm | 6800 |
| Steering angle | ° | ±33 |
| Oscillating angle | ° | ±10 |
| Vibration frequency (high/low) | Hz | 32/27 |
| Nominal amplitude (high/low) | mm | 1.9/0.95 |
| Excitation force (high/low amplitude) | kN | 405/290 |
| Drum diameter | mm | 1600 |
| Drum width | mm | 2170 |
| Engine model | Shanghai Diesel Engine SC8D190.2G2 | |
| Rated power @2000 r/min | kW | 140 |
| Engine oil consumption | g/kW.h | 223 |
| Hydraulic oil tank capacity | L | 170 |
| Fuel tank capacity | L | 320 |
