China New Road Contruction Machinery Motor Graders Price Gr165

  • China New Road Contruction Machinery Motor Graders Price Gr165
  • USD 46200.84 /Unit
  • 1 Unit
  • 29 Unit
  • 11 days
Product Description
China new road contruction machinery motor graders price GR165

Features:
GRseriesofmotorgraderaremainlyusedintheoperationofroadsurfaceleveling,ditchdigging,slopeleveling,bulldozing,scarificationandsnowremovingontheroad,airportandfarmland.Themotorgraderisthenecessaryconstructionmachineryfordefenseconstruction,mineconstruction,urbanandruralroadconstructionandirrigationworksandfarmlandimprovement.

FeaturesofXCMGMotorGraderGR165WithZFGearBox

•Newappearance.
•Theadoptedarticulatedframeassiststhefrontwheeltosteer,featuringsmallturningradiusandflexibility.
hydrauliccontrolledbrakepowershiftgearboxincludes6Forwardgears,and3Reversegears.
•Theadoptedinternationalmatchedhydraulicpartsensurethereliableoperation.
•Theblademovementishydrauliccontrolledfully.
•Therearaxleisthree-waydriveaxlewithNO-SPINself-lockingdifferential.
•Thereasonabledistributionoftheadjustableoperationpanel,seat,leverandinstrumentguaranteesthecomfortableandconvenientoperation.
•Theluxuryandbeautifulcabfeatureswidevisibilityandgoodsealing.
•Themachinecanbeequippedwithfrontbulldozingplate,rearscarifier,frontharrowandauto-levelingsystem.

Contact way:
Sales Manager
April Chen
Newindu E-Commerce(Shanghai)Co.,Ltd.
Add:Suit 1326, Fortune Times Tower, No. 1438 North Shanxi Road, China
Mobile :+86-135 8550 0864
Web:http://www.evangelchina.com
Our company:
Newindu E-commerce (Shanghai) Co., Ltd. is aleading Chinese construction machinery exporter, located in the downtown of Shanghai City. Since our company was founded, based on the advantage of XCMG which is the No. 1Chinese construction machinery manufacturer, we continually introduce Chinese excellent construction machinery enterprises and their products to international markets, such as Changlin, Zoomlion, LiuGong, HOWO, Shantui, HBXG, YTO, SDLG etc. We not only make more international customers know and approbate our products, but also gradually build up friendship with construction machinery customers all over the world.

Out products:

1) ALL kinds of trucks.
(Dump Truck, mining dump truck, tractor truck, truck trailer ,towing truck ,water tank truck, concrete mixer truck, oil tank truck, Garbage Truck, Cargo truck, port terminal tractor, refrigerated truck, Truck Mounted Crane, fire truck, suction sewage truck, bus ,etc)

2) All kinds of construction machinery.
(Wheel loader, excavator, folklift, cranes, paver, road roller etc.)

Need more information? Just contact me please!

Parameters:

Engine modelD6114
Rated power/speed125kW/2300rpm
Dimension(LxWxH)8900×2625×3470mm
Operating weight(Standard)15000kg

Performance specification

Travelling speed ,forward5,8,11,19,23,38 km/h
Travelling speed ,reverse5,11,23 km/h
Tractive force(f=0.75)77KN
Max. gradeability20%
Tire inflation pressure260 kPa
Working hydraulic pressure16 MPa
Transmission pressure1.3~1.8MPa

Operating specification

Max. steering angle of front wheels±50°
Max. lean angle of front wheels±17°
Max. oscillation angle of front axle±15°
Max. oscillation angle of balance box15
frame articulation angle±27°
Min. turning radius using articulation7.3m
Biade
Maximum lift above ground450mm
Maximum depth of cutting500mm
Maximum blade position angle90°
Blade cutting angle28°-70°
Circle reversing rotation360°
Moldboard width X height3965×610mm

SpecificationModel

GR135

GR165

GR180

GR215

Engine model

6BT5.9

D6114

6CTAA8.3 /D6114

6CTAA8.3 / 6CTA8.3

Rated power/speed

100/2200kw/rpm

125kW/2300rpm

138kW/2200rpm

140kW/2300rpm

153kW/2200rpm

160kW/2200rpm

Dimension(L*W*H)

8015*2380*3050mm

8900*2625*3470mm

8900*2625*3470mm

8970*2625*3470mm

Operating weight(Standard)

11000kg

15000kg

15400kg

16500kg

Performance specification

Travelling speed ,forward

5/8/13/20/30/42km/h

5/8/11/19/23/38 km/h

5/8/11/19/23/38 km/h

5/8/11/19/23/38 km/h

Travelling speed ,reverse

5/13/30km/h

5/11/23 km/h

5/11/23 km/h

5/11/23 km/h

Tractive force(f=0.75)

61.3KN

77KN

79KN

82KN

Max. gradeability

20%

20%

20%

20%

Blade

Maximum lift above ground

410mm

450mm

450mm

450mm

Maximum depth of cutting

535mm

500mm

500mm

500mm

Maximum blade position angle

90°

90°

90°

90°

Blade cutting angle

28°-70°

28°-70°

28°-70°

28°-70°

Circle reversing rotation

360°

360°

360°

360°

Moldboard width X height

3710×610mm

3965×610mm

3965×610mm

4270×610mm
