China Top Sale Front Crawler Excavator Machinery Sy500h

China top sale front crawler Excavator Machinery SY500H

Feature

Several attachments and work tools are available to satisfy European and American high-end market demand.

Multiple counterweight weights available. Easily removable to satisfy various transportation regulations and requirements.

The new generation Cummins engine meeting T4F emission standards of the European and American markets.

Operator selectable work modes and all aspects ofthe machine configuration can be displayed on the operator monitor screen for operator convenience.

The widened, heated suspension seat was carefully selected based on many hours of operator feedback.

Parameters

Engine
Engine model
Cummins QSB12
Rated power
298/2100 kW/rpm
Max. torque
2034/1400 N·m/rpm
Displacement
11.8 L
Emission standard
Tier 4 Final / EU Stage IV
Operation Range
Operating weight
50100 kg
Max. digging height
10929 mm
Max. digging depth
7705 mm
Max. dumping height
7647 mm
Max. vertical digging depth
6278 mm
Max. digging reach
12035 mm
Min. swing radius
5216 mm
Height at min.swing radius
9103 mm
Dimensions
Transport length
12103 mm
Transport width
3596 mm
Transport height
3874 mm
Upper width
3290 mm
Tail swing radius
3765 mm
Min. ground clearance
560 mm
Undercarriage/Working Device
Std. track shoe width
600 mm
Bucket capacity
2.2 m³
Upper rollers
2
Lower rollers
9
Track gauge
2740 mm
Track length
5440 mm
Boom length
7000 mm
Arm length
3350 mm
Performance
Travel speed
5.2/3.0 km/h
Swing speed
8 rpm
Gradeability
35°
Ground pressure
84.5 kPa)
Tractive force
339 kN
Bucket digging force
200 kN
Arm digging force
223 kN
Service Refill Capacities
Fuel tank
680 L
Hyd tank
480 L
Engine oil
34 L
Engine coolant
23.2 L
Hydraulic System
Boom cylinder bore x stroke
165(115) x 1590 mm
Arm cylinder bore x stroke
190(130) x1850 mm
Bucket cylinder bore x stroke
170(120) x1305 mm
