Sany Stc500 50 Tons Truck Crane Truck Mounted Crane with Euro III

FOB Price: USD 300000.00 /Unit
Min.Order: 1 Unit
Supply Ability: 47 Unit
Delivery time： 12 days

Product Description

SANY STC500 50 Tons Truck Crane Truck Mounted Crane with Euro III

SANY STC500 50 Ton Truck Mounted Crane Mobile CraneExcellent and stable chassis performance /chassis system

Double-axle drive is used, providing good traffic ability and comfortableness under complex road condition with reliable traveling performance.

Engine has the multimode power output function, which reduces power consumption.

The use of tipping over early-warning technology provides high stability and safety of the overall operation.

SANY STC500 50 Ton Truck Mounted Crane Mobile CraneHighly efficient, stable, energy-saving and adjustable hydraulic system

Electrical proportion Hydraulic system load feedback, piston pump, electrical controlled valve and constant power control are applied to provide strong lifting capacity and good micro-mobility.

Unique steering buffer design is adopted to ensure stable braking operation.

SANY STC500 50 Ton Truck Mounted Crane Mobile CraneUltra long, super strong and highly sensitive load lifting capacity

Five-section boom of high strength steel structure and optimized U-shaped cross reduces weight significantly with higher safety rates.

Jib mounting angles are 0°, 15°and 30° which ensures fast and convenient change-over between different operating conditions so as to improving working efficiency of the machine.

SANY STC500 50 Ton Truck Mounted Crane Mobile CraneSafe, stable, advanced and intelligent electric control system

Self-developed controller SYMC specially for engineering machinery is configured.

The adoption of CAN-bus full-digital network control technology ensures stable control signal, simple harness and high reliability.

Timely feedback of data information can achieve the monitoring of the overall working status in real-time.

The load moment limiter equipped with the comprehensive intelligent protection system is used with accuracy within 3% to provide acomprehensive logic and interlock control, thus ensuring more safe and reliable operation.

Capacity	Max. lifting capacity	50t
Dimensions	Overall length	13700mm
	Overall width	2500mm
	Overall height	3810mm
	Axles	4
	Axle distance-1,2	1450mm
	Axle distance-2,3	4200mm
	Axle distance-3,4	1350mm
Weight	Overall weight	40000kg
	Front axle load	14500kg/15400kg with jib
	Rear axle load	26000kg

Engine	Model	WeiChai
	Rated power	251kw/2100rpm
	Rated torque	1430N·m/1300-1500rpm
	Emission standard	EuroV
Traveling	Max. traveling speed	80km/h
	Min.turning radius	11.25m
	Min.turning radius of boom head	13.75m
	Drive train	8 × 4× 4
	Min. ground clearance	230mm
	Approach angle	10 °
	Departure angle	14 °
	Max. gradeability	40%
	Fuel consumption per 100km	≤ 45L

Main Performance	Temperature range	- 20 ºC~ + 45 ºC
	Min.lifting radius	3m
	Tail swing radius of superstructure	3.945m
	Boom section	5
	Boom shape	U-shaped
	Max. lifting moment-base boom	1886.5kN·m
	Max. lifting moment-Full-extend boom	909.4kN·m
	Max. lifting moment-Full-extend boom+jib	391kN·m
	Length-base boom	11.3m
	Length-Full-extend boom	43.5m
	Length-Full-extend boom+jib	59.5m
	Outrigger span(Longitudinal/Transversal)	6×7.2m
	Jib offset	0 ° 15 ° 30 °

Working Speed	Max. single rope lifting speed of main winch(no load)	125 m/min
	Max. single rope lifting speed of auxiliary winch(no load)	125 m/min
	Full extend/retract time of boom	120 / 120s
	Full raise/lower time of boom	80 / 80s
	Swing speed	0~2 r/min
Aircondition	HVAC in up cab	Cooling/Heating
Aircondition	HVAC in low cab	Cooling/ Heating

Sany Stc500 50 Tons Truck Crane Truck Mounted Crane with Euro III

------------------
Amanda
amanda[at]newindu[dot]com
Mobile +8618721040484
Facebook:www.facebook.com/amanda.huang.44
Newindu E-Commerce(Shanghai) Co., Ltd
Made-in-China:newindu.en.made-in-china.com
Evangel Industrial (Shanghai) Co.,Ltd
www.evangelchina.com
Address:Suite 1305, Fortune Times Tower, No. 1438 North Shanxi Road, Shanghai, China

Product Images

Sany Stc500 50 Tons Truck Crane Truck Mounted Crane with Euro III Images 1
