Earthmoving Machinery Front XCMG 3 Ton Wheel Loader Price Lw300kn

Earthmoving Machinery Front XCMG 3 Ton Wheel Loader price LW300KN

Feature
Great strength
Tilt cylinder bore of 160mm, enlarge the boom cylinder bore from 110mm to 125mm, and increase the boom lifting force by 29%.
12-ton strong tilt drawing force guarantees the outstanding adaptation to various tough conditions.
7-ton strong boom lifting force ensures various operation methods of high intensity.
High efficiency
The adopted 125 work pump features large displacement, strong oil supply, and the total time of three devices is only 10.3s.
The turning radius is only 5420mm, short running distance, fast loading speed, saving the fuel and high efficiency.
Single pump distribution, load-sensing steering, large flow, enough power, simple and high efficiency.
High strength
Heavy load design. The front and rear frames adopt box type, featuring thickness and high intensity.
The key structural parts adopt finite-element analysis, ensuring the adaptation to various dangerous working conditions.
Long service life
The key articulated positions feature two-stage dust-proof, less abrasion and longer service life.
Wear resistant blade and bucket teethfeature longer service life.
The hydraulic pipe adopts 24° cone and Oring, settling the issue of leakage.
Easily worn oil pipe is equipped with the protective bush, prolonging the service life.
High factor of full bucket
Long bucket bottom, sharp bucket type, easily cutting in, much material.
Lessen the opening angle, reduce the section, easily push in and lift.
Convenient maintenance
The independent chamber design of the hydraulic oil tank return circuit guarantees the conveninence of the maintenance.
The hood adopts the large side door of sliding upward, featureing large opening angle, and more convenient for access.
The classic dead axle transmission features maturity, stability, and easy maintenance. The parts are easy to replace.
Comfortable operation
The cab features luxury decoration, large space and excellent visibitity.
The adjustable seat features comfortability and elegance.
Key breakthrough in the leading level of the industry.
XCMG starts the vehicle manufacturing technology first in China; Including metal cover part and electrophoretic coating, and featuring high residual value.

Parameters

Item		Specifications	Unit
Rated load		3000	Kg
Rated bucket capacity		1.9	M³
Operation mass		11000	Kg
Dumping height(from ground to main blade plate)		2930
Dumping distance(from the front wheel to main blade plate)		1010
Maximum breakout force		130	KN
Maximum traction force		100	KN
Lifting time of swing arm		5.6	S
Total cycling time		9.8	S
Minimum turning radius(outer edge of bucket)		6020
Minimum turning radius(tire center)		5170
Articulated angle		38	°
Gradeability		28	°
Tire size		17.5-25-12PR
Overall demension of machine(L×W×H)		7250×2482×3290
Engine model		YC6J125Z-T22
Rated power/rotate speed		92/2000	KW/r/min
Travel speed	Gear I(F/R)	0~15/20	Km/h
	Gear II(F)	0~40	Km/h
