Liugong Wheel Loader 2ton 0.78m3 Clg816

LIUGONG CLG816 Wheel Loader 2ton 0.78m3

LIUGONG CLG816 Wheel Loader 2ton 0.78m3

Engine model/modeleYTR4105G69

Rated power/puissance 47KW

Rated load /poids capacite 1600kg

Rated bucket capacity/volume de soute 0.78-1.0m³

Max. Breakout force/force max 62± 5KN

Max. Drawbar pull/ force tractive max 42± 5KN

Turning radius outside tires 4370± 50mm

Turning radius outside bucket 4695± 50mm

Overall dimension L× W× H/dim 7380× 2990× 3390mm

Operating weight /poids operation 5300± 300kg

Ultra-large comfortable safe cab space @Ultra-large comfortable safe cab space with apanoramic visibility @Dustproof, sound and shock absorption, heatproof plus ultraviolet radiation-proof @Panoramic rearview mirror @Professional-made and sofa driver seat

Duriable and efficient guarantee @Toughly tested rigid structure proves stable @The bucket is designed and produced with stiffener board to prevent bending deflection. @Integral-type board prevent scattering of material and guaranteed the most material loading quantity

Outstanding Zzigzag linkage mechanism @Powerful breakout force and lifting force means fast lifting and large loading. @Large rollback angel provides steady material loading ability. @Controls dump speed: Lower dump speed guaranteed the safety of stevedore and linkage mechanism

Warmwind: workingmedium

coolingwaterofdieselengine

Warmwind: heatingcapacity

5000kcalories

Coolwind: electricfanof24VDC

-

Fueltank

100L

Coolantsystem

27L

Crankcase

13L

Converter-transmissionsystem

30L

Axles(differentialgearanddecelerator)

-

Frontaxle

8L

Rearaxle

8L

Hydraulicsystem

90L

System

24V

Battery

twoBA31750T

Bulb

24V

Startingmotor

24VDC

DieselEngine

-

RatedRotateSpeed

-r/min

Max.Torque

-r/min

FanDiameter(AirExhaust)

-mm

RatedPower

47kw

EngineYTR4105G69dieselengine

-

Water-cooled. 4-strokecycle, directinjectiondieselengine

-

Ratedspeed

2400r/min

BoreXstroke

4-Φ 105mm× 120mm

Max. nettorque

220.7N. m± 5%

Fuelconsumptionperhourinratedpowerandspeed

≤ 235g/KW. h

Equippedwithelectricalfuelgaugeandpreserveddip-stickforoil-checkingconvenience.

-

BucketCapacity

0.78m3

RatedLoad

1600kg

LiftingTimeofActingArm(FullLoad)

-s

SumofThreeItems

-s

Traction

-kN

Max.BreakoutForce

62± 5KNkN

Max.ClimbingGradient

-°

WeightofLoader(withcabincluded)

-kg

OperatingWeight

5300± 300kg

stype

Articulatedframe. Fullhydraulicsteering

Steeringangle(leftandrightrespectively)

38°

Steeringpump

gearpump(workingpumpalso)

Steeringcylinder-boreXstroke

Φ 60mm× 292mm

Flow

38L/min

Reliefvalvesetting

14MPa

Specification

16/7020

Layer

10

systemworkingpressure

17.5MPa

Boomcylinder-boreXstroke

Φ 80× 605mm

Tiltcylinder-boreXstroke

Φ 100× 407mm

------------------
