JAC Truck /Cargo Truck (1063 W118)

4*2Lighttruck
1. Original parts
2. Quick quotation
3. Good quality
4. Reasonable price

JAC TRUCK TIPPER DUMP DUMPER SEMI-DUMP SEMI-TIPPER ConSTRUCTION TRUCK LIGHT TRUCK
15CBM 18CBM 20CBM 32CBM 42CBM

JAC
Truck part, light truck, Cargo truck, CBU truck, tipper truck, Van truck, Refrigerator truck, Freezer truck, Dump Truck, JAC truck, JAC, truck. Lorry.

Model	HFC1040K/KR1	Max Load Capacity(kg)	2500
Cabin	Single/King Cab	Gross Vehicle Weight(kg)	4930
Engine	YD480	BGI BGI Min Turing Radius(m)	7
Type	in line-4, ind-cooler turbocharged, diesel	Min Ground Clearance(mm)	185
Displacement (cc)	2771	Max Speed(km/h)	90
Compression Ratio	17	Seating Capacity	2
Max Power (HP/rpm)	68kw/3600	Max Gradeability(%)	30
Max Torque (N. m/rpm)	202/2100-2300	frame Section Size(mm)	170*70*5
Transmission	LG5-15	Configuration
Speed Ratio	5.529, 2.782, 1.641, 1, 0.785, R, 5.271	Air Conditioner	ο
Gear Position	1 3 5 2 4 R	Power Steering	ο
Final gear ratio	D803-6.142	Pre-heater	√
Brake system	hydraulic brake	Sidebumper	√
Tyre	6.50-16	Rear bumper	√
Overall Size(mm)(L*W*H)	5745*1866*2213	Wind deflector	ο
Rear body size(mm)(L*W*H)	3930/3600*1770*400	Digital Radio	√
Tread (front / rear )(mm)	1420, 1440/1395	Exhaust Braking	ο
Wheelbase(mm)	3000	New model cabin	√
Curb Weight (kg)	2300
