JAC Light Truck Hfc 1063 E22-Vt

1. Original parts
2. Good quality
3. Quick quotation
4. Reasonable price

JAC
Truck part, light truck, Cargo truck, tipper truck, CBU truck, Van truck, Refrigerator truck,Freezer truck, Dump Truck, JAC truck, JAC, truck.

( √ : Standard Equipment O: Optional ø : Under develop ).

Model	HFC 1063 E22-vT	Max Load Capacity(kg)	4000
Cabin	Single Cab	Gross Vehicle Weight(kg)	8045
Engine	CA4110	Min Turing Radius(m)	8
Type	in line-4, diesel	Min Ground Clearance(mm)	215
Displacement (cc)	4752	Max Speed(km/h)	98
Compression Ratio	17	Max Gradeability(%)	32
Max Power (HP/rpm)	110/2800	frame Section Size(mm)	190*65*6
Max Torque (N. m/rpm)	305/1700	Configuration
Transmission	LC5T30	Air Conditioner	Ο
Speed Ratio	4.776, 2.496, 1.429, 1, 0.728, R\4.774	Power Steering	√
Gear Position	R 2 4 1 3 5	Pre-heater	Ο
Final gear ratio	E4-5.375	Wind deflector	Ο
Brake system	hydraulic brake	Side bumper	√
Overall Dimensions(mm) (L*W*H)	7285*2170*2315	Rear bumper	√
Cargo Dimensions(mm)(L*W*H)	5530*2010*550	Digital Radio	√
Tread (front / rear )(mm)	1665/1600	Exhaust Braking	√
Wheelbase(mm)	4150	New model cabin	ø
Curb Weight (kg)	3850	Else	With Bugle Radiator
