HOWO 3.5 Tons Light Truck 4X2 Cargo Truck

HOWO 3.5 tons light truck 4x2 for sale Cargo truck fence truck

ModelZZ1047D3414C145/H5W4100N17D2035L

Engine	Manufacture: KunmingYunnei Power Co., Ltd Diesel:4-stroke directinjection diesel engine Engine model: 4100YUNNEI,Euro2emission standard 4-cylinder in-line withwater cooling, turbo-charging and intercooling Maximum output:110 HP(85Kw)at3000 rpm according to DIN Maximum torque:330 Nm at 1600~2000 rpm Number of cylinder:4 Displacement:3.76L Bore:102mm Stroke:115mm Compressionratio: 17.5HP/L Specific fuel consumption:220g/Kwh Thermostat with 71ºC temperaturesaver Rigid fan
Clutch	Single-plate diaphragmspring clutch, diameter 300mm,hydraulically operating
Transmission	DC transmission, model WLY6T100,synchromesh,5forward &1 reverse
Front Axle	VGD020QB,forging forming of front axle I-beam, to guarantee the stiffness and highstrength.
Rear Axle	HGC035QB,mature punchingwelding axle and pressed axle housing
Chassis	frame :U-profile parallel ladder frame with section of 170×60×5 mm, all cold riveted cross members Front suspension: 11 leaf springs,shock absorbers and stabilizer Rear suspention:9 main leaf springs+7vice leaf springs, Spare wheel carrier: with one sparewheel Fuel tank: 80 Lcapacity
Steering	LG9704470020,hydraulicsteering with power assistance
Brakes	Service brake: dual circuitcompressed air brake Parking brake (emergencybrake):spring energy, compressed air operating on rear wheels (optional) Auxiliary brake: engineexhaust brake (optional)
Wheels &Tyres	Tyres: 7.00R16
Driver's Cab	Single cab with one sleeper, 45° hydraulically tiltable to thefront,2-arm windscreen wiper system with three speeds, adjustable driver'sseat, with heating and ventilating system, interior double sun visor,sunroof, radio and USB interface, safety belts, adjustable steering wheel,horn.
Electrics	Operating voltage:24 V,negative grounded Starter:24 V,4.5Kw Batteries:24 V,80Ah Cigar-lighter, horn,headlamps, fog lights, indicators and reverse light
Instrument Panel	Active check centralcontroller with indicators, with this integral instrument the daily manualchecks on the vehicle and combined indicators of compressed air pressure,coolant temperature, engine oil pressure.
Dimensions in mm	Wheel base3360 Approach angle(°)20 Departure angle(°)18 Overall dimension(L xW xH mm)5995×2000×2450
Weight in kg	Load weight(kg)2000 Gross vehicle weight(kg)4500
Performance	Maximum driving speed(km/h)90 Maximum grade ability(%)30 Maximum ground clearance(mm)210 Maximum turning circle(m)14 Fuel consumption(1/100km)10.1
