40ft Container Tri-Axle Flatbed Trailer

40ft container Tri-axle Flatbed Trailer
Flatbed bed container semi-Trailer, Flatbed Semi Trailer,
Container Semi Trailer, Semi Trailer, Semi-Trailer, Trailer and etc.
1. Tare Weight 6200kg
2. Payload 35000kg
3. Chassis: Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes. Top Flange 14mm, width 140mm; Middle Flange 6mm, height 500mm; Bottom Flange 16mm, width 140mm.
4. Axle: 2/3 axles of Germany design 12ton, 13 ton, 16 ton axle optional upon choice
5. Brand Name: FUWA -optional BPW
6. Suspension: Germany design heavy duty mechanical suspension or air suspension optional upon choice
7. Floor: 3mm checker plate Leaf Spring Doll type Leaf spring
8. King Pin: JOST brand 2" Bolt-in King Pin
9. Landing Gear: JOST brand Two-speed, manual operating, heavy duty Wheel Rim 8.25-20, 9.0-20, 8.25R22.5, 9.0R22.5, 11.75R22.5 steel wheel rim optional upon choice
10. Tyre: 11.00R20, 12.00R20, 11R22.5, 12R22.5 tire with one spare tire optional upon choice
11. Twist Lock: 12 nos. Of ISO twist lock for 1X20ft, 2X20ft; 1X40ft container, the retractable central locks can be laid down. Spare Tire One set of spare tire including a carrier
12. Braking System: WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 45L air tanks
13. Painting Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
14. Accessories One standard tool box

Product Information
Product	container flatbedsemi trailer
Brand Name	HTCBrand
Model Number	HTC9406TJZ
Announcement (batch)	226
Place of Origin	Shangdong province, China
Color	Any color will be available
Manufacturer	QINGDAO HETANCH TRUCKCo., Ltd
Product Specifications
Total Weight		46500 kg
Rated Load		40000 kg
Tare Weight		6500 kg
Wheel base		6900+1350+1350 (mm)
Tyre Specifications		11.00R20 20PR 12R22.5 20PR (Tubeless tyre or Radial tyre)
No. Of the Tyres		12
Axle Brand		FUWA (BPW optional)
No. Of the Axles		3
Axle-load		16000 kg
Pieces of leaf-spring		10 (8)
Suspension		Independent stamping steel rigid suspension ( air suspension)
Departure Angle		17
Front/Rear Overhang		2135 mm
Outside Dimensions (LxWxH)		12400x2500X1600 (mm)
Twist lock		8/12 pcs
Material of the Main Beam		Q345A manganese plates, automatic submerged arc welded
Brake System		Air braking(ABS is optional )
Brake Air Chamber		Four double and two single chamber
Usage		40ft and 20ft container
Other Descriptions		The cargo's carring part of the stake truck is store house bar style designed, the beam wears through the longitudinal beam which is welded as a space frame structure, making the frame strength, stiffness, flexibility an equilibrium, a strong carrying capacity without permanent deformation.
