Introduction of compress garbage truck
Thecompress garbagetruckusually calledgarbage compactor truck,compression garbage truck,waste compactor truck,compactor garbage truck,etc.

Thecompress garbage truckusually compacts the waste using a hydraulically powered mechanism that employs a moving plate or shovel to scoop the waste out from the loading hopper and compress it against a moving wall. In most compactor designs, the plate has a pointed edge (hence giving it the industry standard name packer blade) which is designed to apply point pressure to the waste to break down bulky items in the hopper before being drawn into the main body of the truck.

Thegarbagecompactortruck we maufacture isanidealcompactorforlargeclean upoperations.Itissimpletooperateandhighlyeffectivewithexcellentcompactionratio.Itisideallysuitedtomunicipalapplicationswherelargeamountsofmixedindustrialanddomesticrefuseistobecollected.

Ourgarbagecompactortruck for sale isconsistedoffourmainparts,sealedgarbagecompartment,hydraulicsystem,operatingsystemandliftingcylinder.fullysealed.Itcancompactanddumpthe
garbageautomotically.Thesewagewillflowinthecompartmentcompletelytoaviodre-polluteduringtransportation.

As a professional special vehicle manufacturer in China,the garbage compression truck we produce is from 4cbm to 18cbm

FAQ

1.Payment:30% deposit after order /confirm/iation, 70% balance should be paid before delivery.All byT/T, L/C.
2.Delivery time:25 working daysafter payment is received.

Packaging &Shipping:

1. Naked or waxed before on board.
2. Delivery time: 30 days after receiving payment in advance.
3. By RORO or Bulk ship.

Our warranty:

1. One year quality guarantee for three key parts: Axles, engine, transmission.
2. Other spare part could be supplied by OEM at cost prices.
3. Regularly callback to know the vehicle's working status.
4. The overseas engineers are always ready to deal with unexpected needs.

Below specification is just for your reference. More information of ourGarbage Trucks, please feel free to contact withMs. Nancy Wang. We will customize the truck according to your requirement.

Sales Manager: Nancy Wang
Mob.: 0086-181 86127295

Description	Dongfeng Compression Garbage Truck Garbage Compactor Truck
Drive Model	4X2
Chassis	EQ1060TJ20D3
Vehicle Main Dimensions	Dimensions(L x W x H)mm	6320×2050×2560
	Wheel base (mm)	3300
	Overhang (front/rear) (mm)	1032/1988
	Wheel track (front/rear) (mm)	1506/1466
	Approach/Departure angle(°)	19/10
Weight in KGS	Curb Weight	5365
	GVW.	6495
Max. driving speed(km/h)		90
Engine	Model	YC4F90-30
	Type	4-stroke direct injection , 4-cylinder in-line with water cooling, turbo-charging and inter-cooling
	Horse Power(HP)	90HP
	Emission standard	EuroIII
Gearbox	5forwards & 1 reverse
Clutch	Reinforced diaphragm clutch
Steering Gear	Power steering, hydraulic steering with power assistance
Fuel tank (L)	150
Tire	7.00-16 tire ,6+1 spare
Brakes	dual circuit compressed air brake
Allowable passengers in cab	2
upper
Volume(kg)	1000
Material	Q235carbon steel
Thickness	5mm
Uploading cycling time	<60s
Loading cycling time	≤30s
Lifting capacity	≥800KG
Operation control system	Electrically hydraulic control
Equipment	Equipped with dustbin, hydraulic system and operating system Equipped with two advanced double acting hydrocylinders One vehicle can cooperate with several dustbins to improve the ability of cycle operation.cycling time60s

Our advantages:
a.CompetitivePriceandExcellentQuality,
b.Morethan10years'experienceasamanufacturer
c.CCC,ISO,BVcertification
d.Perfectafter-saleservice
e.Customizedproductsavailablewithus,
f.ExportcoveringMorethan50countriesandregions
g.Annualproductionvaluetopped1500,000,000RMB(240,000,000USd ollars)peryear
