Dump Truck HOWO Sitrak C7h Heavy Truck 400HP 4X2 Tractor

Dump Truck HOWO SITRAK C7H Heavy truck 400hp 4X2 tractor



*Powerful and reliable engine.

*Large loading capacity.

*Strong bucket.

*Reliable and Popular, especially in Africa, south America, Middle East and south East

Asia.

*Better servce.

*Technology and parts supports, one year warranty for engine, gearbox, axle, etc.

Basic information

Announcement model	ZZ4186V361HE1W	driven form	4X2
Wheelbase	3600mm	engine	China heavy steam Mc11.40-50
Gearbox	ZF16S1950	rear axle speed ratio	3.36
Body length	6.22m	body width	2.496 m
Body height	3.62m	wheel pitch	front wheel distance: 2022mm Rear wheel distance:1816mm
Total weight	6.8 t	gross quality	18 t
Total quality	35 t	Market segment	dangerous transportation
Origin	jinan	note	dangerous goods transport

The engine

Engine	China heavy steam Mc11.40-50	cylinder number	6
Fuel type	diesel	cylinder arrangement	direct column
Emissions	10.518L	emission standard	China 5 / euro 5
Maximum horsepower	400 hp	maximum output	294kW

Torque	1900N·m	maximum torque speed	1000-1400rpm
Rated speed	1900rpm

Bridge parameter

Cab	high	width	800mm
Total number of passengers	3	seats	half

transmission

Gearbox	China heavy steam HW19712CL	shift gears	manual
Forward gear	12	shift number	2

chassis

suspension form	steel spring
Rear axle allowable load	11500kg	prebridge allowable load	6500kg
Rear axle speed ratio	3.36	spring number	3/5
