XCMG Official Manufacturer Jp60 Water Tower Fire Truck

XCMG official manufacturer JP60 Water Tower Fire Truck
[Product Description]
German Benz Actros4144 four-axle chassis, power 320kw, 5-section telescoping boom + 1-section folding jib structure; equipped with large capacity fire tank of 5.2t water and 1t foam, automatically-controlled foam ratio mixing system, American Darley PSP1500 fire pump and imported electro-controlled monitor; water monitor is installed on tank top fire fighting operation; electro-hydraulic proportional control technology makes high rescuing efficiency and convenient operation; 40m cable remote control and fire site monitoring system are available. It is the hightest water tower fire truck.

[Product Parameter]
Category Item
Unit
Parameter

Dimension Overall length mm 13440
Overall height mm 4000
Overall width mm 2500

Weight

Extinguishane rated load weight Water kg 5200
Foam kg 970
Toatail vehicle curd weight kg 33880
Toatail vehicle weight kg 40200

Travel
performance Max.travel speed km/h ≥90

Main performance Rated working
height m 60
Max.working radius m 22

(×) Outrigger span
(longitudinal×lateral) mm 6750×5430

Working speed Boom depl
oying time s ≤140
Outrigger extending time s ≤40

Fire-fighting performance fire pump
rated flow L/S 50
fire pump
rated pressure Mpa ≥1.7
(/)
Water monitor(boom monitor/root monitor) Water monitor
rated flow L/S 50/60
Water monitor
rated reach m 70/75

Foam monitor
rated flow L/S 48/48
Foam monitor
rated reach M 60/50

[Company Information]
XCMG was born in 1943 as an arsenal workshop during the War Against Japanese Aggression and has a history of 72 years.The group was incorporated in 1989, and has kept its leading position in Chinese construction machinery industry for 26 years.If you want know more about us, you can also visit our web site: http://www.xcmg.com/en-mena/.

According to KHL's Yellow Table, XCMG ranks No.8 in the world construction machinery industry in 2014.According to the rank of Top50 Summit of World Construction Machinery Industry, XCMG ranks No.5 in the world.

At present, XCMG is a large state-owned international corporation with the most complete range of products and over 30,000 employees operating in China, America, Germany, Netherlands, Poland, India, Brazil and Uzbekistan.

The goal of XCMG is to become a leading world-class enterprise with great value creativity.
