2 Axle Flatbed Container Trailer for 20FT 40FT Container Trailer
- USD 10050.00 /Unit
- 1 Unit
- 78 Unit
- 8 days
Product Description
2 Axle Flatbed Container Trailer for 20ft 40ft Container Trailer
Contact:Grace Wang
Phone: (+86) 183 5414 5160
| Main specification | |
| Type | two axle skeleton semi trailer |
| Function | Carry20ft container or other stuff |
| Overall dimension | 7500x2500x1550 |
| Container twist lock | 4 pcs container locks |
| Loading weight | 35000kgs |
| Main beam | Material: Carbon steel Q345B The height of the beam is 500 mm, upper plate is14mm, down plate is 16mm, middle plate is 8mm. |
| Board thick | 1.5mm Carbon steel Q235 |
| side beam | 16 Ushaped steel Q235 |
| Chassis | |
| Traction pin | 3.5 inch or 2inch optional |
| Tire | 12R22.5 |
| Support legs | 28Ton standard |
| Steel spring | 10/10/10 Leaf Spring Suspension |
| Axle FUWA brand | 13 ton axle* 2pcs |
| Accessories | |
| Tool box | 1 unit |
| Brake system | Dual Line braking system ,none ABS. |
| Brake air chamber | 2 pair double and one pair single chamber |
| Electrical system | 1. Voltage: 24v 2. Receptacle: 7ways (7 wire harness) |
| Tail lamp with turn signal, brake light &reflector, side lamp etc. | |
| One set 6-core standard Cable. | |
