/Xs143j Mechanical Single Drum Road Roller Construction Machinery
- Price can be negotiated
- 1 Unit
- 61 Unit
- 30 days
1.Main Purposes of road construction machinery.
Can be widely used in highways, airports, embankment fill, harbors, dams, railways, mines and other compaction depth and efficient construction.
2. Main parameters of road construction machinery.
1). Machinery single drum vibratory roller
2). imported open gear pump and motor;
3). Without Air conditioner;
4). Shanghai Diesel Engine 114 series water-cooled engine 92kw EURO II;
5). Ovevrall size:6010x2340x3200mm
6). Operating weight:14000Kg
7). Static linear load:322N/cm
8). Vibration frequency(High/Low):28Hz
9). Engine model:SC5D125G2B1
10). Rated power:92Kw
11). Engine oil consumption:230g/kW.h
More details please check the table.
3.Visual appearanceof road construction machinery.
4. More construction equipmentof us:
* Construciton crane sector: Truck Crane / All Terrain Crane / Crawler Crane / Tower Crane/ Truck Mounted Crane / Aerial work machinery
* Road machinery sector: Paver / Mixer station / Milling machine / Mixing plant/Cold recycling / Mixing station / Asphalt pavement / Road roller / Grader
* Agricultural equipment machinery: Mini-excavator / Backhoe loader
* Sanitation construction machinery: Detachable container garbage collector / Compression refuse collector
Expect your inquiry at any time for any product.
| Working performance parameters | ||
| Static linear load | N/cm | 322 |
| Vibration frequency(High/Low) | Hz | 28 |
| Nominal amplitude(High/Low) | mm | 1.9/0.95 |
| Excitation force(High/Low) | Kn | 274/137 |
| Driving performance parameters | ||
| Speed I | Km/h | 2.7 |
| Speed II | Km/h | 4.8 |
| Speed III | Km/h | 10.5 |
| Theoretical grade ability | % | 30 |
| Min. external turning radius | mm | 6800 |
| Steering angle | ° | ±30 |
| Oscillating angle | ° | ±11 |
| Basic parameter | ||
| Operating weight | Kg | 14000 |
| Weight on rear wheel | Kg | 10000 |
| Weight on front drum | Kg | 7000 |
| Overall size | mm | 6010x2340x3200 |
| Sheep foot | With removable sheep foot | |
| Engine | ||
| Engine model | SC5D125G2B1 | |
| Type | Water cooled, pressurized | |
| Rated speed | r/min | 2200 |
| Rated power | Kw | 92 |
| Hydraulic oil tank capacity | L | 170 |
| Fuel tank capacity | L | 180 |
-
