Mini Excavator Xe230c

about us:
Shandong Shanglong economic and trade corporation ltd is located in Jinan city, the capital of Shandong province, P. R. China. With more years developing, we specializes in exporting SINOTRUK series trucks such as tipper, tractor, mixer, Cargo truck, special-using truck, semi-trailer and spare parts.
X-CMG and ZOOOMLION series construction machinery such as truck crane, wheel loader, excavator, road roller, pump truck and original spare parts.
We have been exporting trucks and constructions machineries to many countries across the world and the products than we offer have attained many certification such as ISO9001, ISO14001, CE, EU, GOST, and enjoy a high reputation for their high quality and competitive price.
Adhere to the belief, preciseness, diligence, progress, innovation; Our company will spare no efforts to dedicate itself to the satisfaction and benefit of our customers, please just send us your inquire with the detailed specification and quantity, we will then send you our breathtaking offer immediately. You are assured of our best quality products and the strongest support.
The faster movement will definitely get you the more market share and profits.


Our light duty truck factoy was established in 1956, have 3000 staffs, including 300 professionals and technical personnel. The factory covers an area of 600, 000 square meters construction area, We have more than 20 automobile production lines of stamping, welding, painting, assembly and testing and so on, all of that use computer control. Our annual production capacity is 100, 000 pcs of light duty truck and other special using mini truck.

Model			XE230C
Bucket capacity		m3	1.0
Standard bucket width		mm	1,260
Operation weight		kg	23,520
Dimension(in transportation)	Overall length	mm	10,160
	Overall width	mm	2,990
	Overall height	mm	3,050
	Min. clearance	mm	485
Engine	Model		CC-6BG1TRP
	Total displacement	L	6.494
	Rated output power	KW/rpm	125/2100
Digging performance	Max. digging height	mm	9,670
	Max. dumping height	mm	6,795
	Max. digging depth	mm	6,920
	Max. vertical digging depth	mm	6,165
	Max. digging radius	mm	10,270
	Boom deflection angle	°
	Min. slew radius	mm	3,870
	Min. rear slew radius	mm	2,940
	Bucket digging force	kn	163
Track type			Steel
Track width		mm	600
Travel System	Track length	mm	4,255
	Wheel base	mm	3,462
	Track gauge	mm	2,390
	Travel speed (Gear I/II)	km/h	5.5/3.5
	Gradeability	%	70
Slew speed		rpm	12.1
Bulldozing plate	Bulldozing plate width	mm
	Bulldozing plate height	mm
	Lifting distance	mm
Hydraulic pump type			Variable pump×2
Slew motor type			Piston hydraulic motor
Travel motor type			Piston hydraulic motor
Fuel tank capacity		L	400
Hydraulic oil tank capacity		L	240
