/China 13.5t Kubota Crawler Excavator Low Price
- Price can be negotiated
- 1 Unit
- 50 Unit
- 24 days
Product Description
Product Feature And Advantage
1.Special design on separating engine and radiation space, using enhanced cooling fan to increase cooling efficiency.
2.Famous brand hydraulic system parts ensure the stable quality.
3.Equipped with double fuel filter to guarantee fuel purity to protect engine.
4.Extend hydraulic line for various attachments.
5.Comfort cabin, wide and open sight make operator easy to work.
6.imported pilot control joystick make your operation easy &joyful.
7.Strong structural parts make sure the working quality duration.
Technical Specification
Engine
Main Performance
Hydraulic System
Overall Dimensions
Operation parameters
Our company passed the ISO9000 quality management system, ISO10012 measurement management system, ISO14000 environmental management system, OHSAS18000 occupational health and safety management system and standardization of certification of good conduct business; All automotive products have passed national CCC certification. We are identified as provincial-level enterprise technology centers and high-tech enterprises of provincial-level.
For more details, please send your requirement to my email or call me directly. Let me help you to choose the best excavator.
Looking forward to your inquiry at any time, Thanks!
Liu Lin
Tel: +86-17661047475
1.Special design on separating engine and radiation space, using enhanced cooling fan to increase cooling efficiency.
2.Famous brand hydraulic system parts ensure the stable quality.
3.Equipped with double fuel filter to guarantee fuel purity to protect engine.
4.Extend hydraulic line for various attachments.
5.Comfort cabin, wide and open sight make operator easy to work.
6.imported pilot control joystick make your operation easy &joyful.
7.Strong structural parts make sure the working quality duration.
Technical Specification
Engine
| Model | ISUZU GJ-4JJ1XKSC0173KW |
| Type | Direct injection, water cooled, supercharge |
| No. of cylinder | 4 |
Main Performance
| Swing Speed | r/min | 0-12 |
| Traveling Speed | km/H | 2.8-4.2 |
| Grade ability | % | 70(35°) |
| Bucket Digging Force | kN | 91 |
| Arm Digging Force | kN | 55 |
Hydraulic System
| Hydraulic system working pressure | Mpa | 32 |
| Hydraulic Pump | KPM | |
| Hydraulic Valve | Doosan/Parker | |
| Swing Motor | Sunjin | |
| Traveling Motor | Doosan |
Overall Dimensions
| Overall Length | mm | 7635 |
| Overall Width | mm | 2500 |
| Overall Height | mm | 2750 |
| Mini Ground clearance | mm | 400 |
| Track width | mm | 500 |
| Undercarriage width | mm | 2500 |
| Undercarriage ground clearance | mm | 400 |
Operation parameters
| Operation Weight | KG | 13500 |
| Bucket Capacity | m3 | 0.6 |
| Max. Digging Radius | mm | 8000 |
| Max. Digging Depth | mm | 5095 |
| Max. Digging Height | mm | 8540 |
| Max. Dumping Height | mm | 6125 |
| Max. Dozer Cutting | mm | |
| Max. Dozer Lifting | mm | |
| Tail Swing Radius | mm | 2420 |
Our company passed the ISO9000 quality management system, ISO10012 measurement management system, ISO14000 environmental management system, OHSAS18000 occupational health and safety management system and standardization of certification of good conduct business; All automotive products have passed national CCC certification. We are identified as provincial-level enterprise technology centers and high-tech enterprises of provincial-level.
For more details, please send your requirement to my email or call me directly. Let me help you to choose the best excavator.
Looking forward to your inquiry at any time, Thanks!
Liu Lin
Tel: +86-17661047475
