Product Description

Lifting Above Ground 450mm 1.5t Grader
Grader GR1803

Engine model6CTAA8.3 D6114Max. steering angle of front wheels±50°
Rated power/ speed138kW/2200 140kw/2300rpmMax. lean angle of front wheels±17°
Dimension8900x2625x3470mmMax. oscillation angle of front wheels±15°
Operating weight (Stander)15400kgMax. oscillation angle of balance wheels15
Travelling speed, forward5, 8, 11, 19, 23, 38 km/hframe articulation angle±27°
Travelling speed, reverse5, 11, 23 km/hMin. turning radius using articulation7.3m
Tractive force (f=0.75)79KNMaximum lifting above ground450mm
Max.gradeability20%Maximum depth of cutting500mm
Tire inflation pressure260kMaMaximum blade position angle90°
Working hydraulic pressure16MPaBlade cutting angle28°-70°
Transmission pressure1.3~1.8MPaCircle reversing rotation360°


Moldboard width X height3965x610mm














Product Images
Lifting Above Ground 450mm 1.5t Grader Images 1
