Sinotruk HOWO 6X4 Water Tank Truck

HOWO 6*4 Water tank truck

The description of Water Truck:

Water Tank Truck, also known as virescence spraying vehicle and water tanker, is mainly composed of truck chassis, water inlet and outlet system and tank body. Water Truck has various spray and water-carrying functions according to different environments and purposes.

The application of Water Tank Truck:

Water Truck is suitable for the virescence and environmental protection of urban residential area and factories.

Item Technical parameters
Chassis model: ZZ1251M4441W
Dimension(LxWxH) (mm): 9795x2495x3070
Wheelbase (mm): 4350+1350, 4350+1300
Track front/rear (mm): 2047/1820
Tire specification: 11.00-20, 11.00R20
Chassis manufacturer: China National Heavy Duty Truck Group Co., Ltd.
Engine model: WD615.62, WD615.87
Max. Power (kw/r/min): 196/2200, 213/2200
Engine manufacturer: China National Heavy Duty Truck Group Co., Ltd.,
Front overhang / rear overhang (mm): 1320/2775, 2825
Approach angle / Departure angle: 15/10
Max. Speed (km/h): 90
Max. Total mass (kg): 24980
Kerb mass (kg): 12400
Rated loading mass (kg): 12450
Tank effective volume (m3): 18.1
Working speed (km/h): 5-10
Pumping capacity (L/min): 900
Sprinkling width (m): 14-18
Anti-aircraft spray gun vertical gunshot(m): 26

Welcome to visit our company in China

Suizhou DongTe Special automobile Co., Ltd is a special purpose vehicle manufacture that has the capacity of self-research and development

The main products are

1. Chemical liquid truck

2. Water truck

3. Fire engine truck

4. Truck mounted with crane

5. Dump Truck, tipper, heavy duty truck

6. Fuel Tanker Truck

7. Van truck, insulated truck, refrigeration truck

8. High altitude working truck

9. Fecal suction truck, Sewage Suction Truck

10. Concrete mixer

11. Self-loading Garbage Truck, garbage compactor truck, sealed garbage truck

12. Bulk Cement Truck

13. Low plate semi-trailer, oil semi-trailer, van semi-trailer, bulk cement transportation semi-trailer, container semi-trailer, chemical liquid semitrailer, etc more than 300 types in total.

Item	Technical parameters
Chassis model	ZZ1251M4441W
Dimension(L×W×H) mm	9795×2495×3070
Wheelbase mm	4350+1350,4350+1300
Track front/rear mm	2047/1820
Tire specification	11.00-20
Chassis manufacturer	China National Heavy Duty Truck Group Co., Ltd.
Engine model	WD615.62,WD615.87
Max. power kw/r/min	196/2200,213/2200
Engine manufacturer	China National Heavy Duty Truck Group Co., Ltd., Weichai Power Co.,Ltd.
Front overhang / rear overhang mm	1320/2775,2825
Approach angle / Departure angle°	15/10
Max. speed km/h	90
Max. total mass kg	24980
Kerb mass kg	12400
Rated loading mass kg	12450
Tank effective volume m3	18.1
Working speed km/h	5~10
Pumping capacity L/min	900
Sprinkling width m	14~18
Anti-aircraft spray gun vertical gunshotm	≥26
