0.7 Ton 37kw 0.4m3 Skid Steer Loader with Ce Jc45

Skid steer loader with CE.Main features of JC45
Compact structure, maneuverable movement suitable for narrow space operation
Open cabin with mechanical control system
Double accelerograph control
Multi-function with a wide range of attachments
Hydraulic brake

Model Main technical parameter		JC45G
A	Overall operating height(mm)	3980
B	Height to bucket hinge pin(mm)	3080
C	Height to top of cab(mm)	2140
D	Height to bottom of level bucket(mm)	2913
E	Overall length without bucket(mm)	2640
F	Overall length with bucket(mm)	3420
G	Dumping angle at maximum height(°)	40
H	Dumping height(mm)	2380
I	Dumping reach(mm)	700
J	Rollback of bucket on ground(°)	30
K	Rollback of bucket at full height(°)	104
L	Wheelbase(mm)	991
M	Ground clearance(mm)	185
N	Angle of departure(°)	20
O	Front turning radius without bucket(mm)	1168
P	Front turning radius(mm)	1958
Q	Rear turning radius(mm)	1630
R	Rear axle to bumper(mm)	1108
S	Tread width, centerline to centerline(mm)	1450
T	Width(mm)	1720
U	Bucket width(mm)	1740

Model	JC45
Engine model	490
Bore x stroke(mm)	95×106
Rated power (Kw)	37
Rotating speed(rpm)	2650
Number of cylinders	4
Max. torque (N.m)	156
Displacement (L)	2.67
Max. Speed (km/h)	12
Tire(track) modei	10-16.5
Operating load(kg)	700
Lifting	Arc lifting
Bucket capacity(m3)	0.4
Rated flux(L/min)	75
High Flow Flux(L/min)
Fuel tank capacity(L)	65
Self weight bucket(kg)	3000
