3yj8/10 New Three Wheel Road Roller 58kw

THREE WHEEL ROAD ROLLER

Applications
These rollers are widely used for the final compacting of highway, railway, municipal works, parking ground, industrial ground and square construction works. As well as for paving of gravel, macadam, asphalt and asphalt concrete road face, it is also capable of compacting the road base.

Main Features
1) The hydraulic steering system assures easy manipulation.
2) It has low center of gravity, good stability & large climbing ability.
3) The disk brake and change-over clutch are reliable and durable.
4) The comfortable seat and excellent visibility are its rational design.
5) Service Brake: Hydrostatic; Parking Brake: Mechanical.
6) Pressurized water sprinkler system on both front and rear drums with water spray on/off switch and corrosion free water tank.
7) Wheel scrapers and electrical lighting arrangements on front & rear
8) Speed control lever with neutral start switch, secondary/parking brake switch, engine start/run/stop switch.
9) Steel canopy over driver's seat, also high quality rubber cloth will be provided to protect heat.

Model		3YJ8/10
Roll diameter	Front roll (for steering)	φ1060			mm
	Rear roll (for driving)	φ1500			mm
Roll width	Front roll	1250			mm
	Rear roll	500×2			mm
Linear pressure	Without ballast	>520			N/cm
	With ballast	>650			N/cm
Travel speed	I II III	2	3.5	8	km/h
Diesel Engine	Model	495AY
	Rate power	58			kW
Overall dimension Canopy		4460×2116×2613			mm
