8 Ton Forklift Truck Factory Seller

China biggest Forklift Truck Supplier with good forklift and competitive price

1. Powerful Engine
Engine for optional: CHAOCHAI6102-BG, ISUZU 6BG1, PERKENS 1104D-TA(EUROIII)
2. Hydraulic Gear-box
3. Control Valve
4. Steering Bridge
5. Double Front Wheel
6. Caution Light

Technical Parameters:

Product Name		8 Ton Diesel Forklift Truck
Model		SH80
Load capacity (kg)		8000
Load center (mm)		600
Power type		Diesel
Max. lifting speeds ( with load ) mm/s		350
Max. driving speeds ( with/without load ) km/h		26/30
Max. towing ( with/without load ) kn		58
Gradeability (with/without load ) %		21/20
Lifting height (mm)		3000
Free lift (mm)		195
Tilting angles ( forward-backward ) (.)		6/12
Min. turning radius (mm)		3700
Min. right angle aisel width ( mm )		3310
Min. under-clearance (mm)		250
Dimension	Overall length (including fork)mm	5160
	Overall width ( mm )	2165
	Overall height (mast lowered )mm	2700
	Overall height (mast extend )mm	4375
Overall height to overhead guard (mm)		2585
Fork overhang (mm)		700
Wheel base (mm)		2500
Tread	Front tread (mm)	1600
	Rear tread (mm)	1700
Tyre	Front tyre	9.00-20-14
	Rear tyre	9.00-20-14
Total weight (kg)		10960
Fork width (mm)		170
Fork thickness (mm)		70
Backrest height (mm)		1374
Fork length (mm)		1220
Engine	Engine model	Chaochai6102-BG
	Rate power (KW)	80.9
	Rotate speed at Rate power (rpm)	2500
	Max. torque (nm)	353
	Rotate speed at max torque (rpm)	1650
Battery		2-12 V/80AH
Type of power shift		Tor-non
