8*4 Fresh Milk Transport Tanker Truck
- USD 74267.76 /Unit
- 1 Unit
- 92 Unit
- 23 days
Milk tanker truck, also known as milk, liquid Food Trucks, milk trucks, mainly used for transporting milk, liquid food, cooking oil and other tankers. Tank with food-grade stainless steel, the tank internal requirements clean, no acute angle, external tank insulation to prevent the need for fresh deterioration in general need to add milk in each cabin cip (cleaning device).Milk truck/milk transport truck/milk lorry developed by our company covering SINOTRUK, DFAC, ISUZU, FAW, FOTON, JAC, JMC brand, having characteristics such as high intensity, fire retardant, waterproof, static proof, fireworks alarming.
Product description
| 8x4fresh milk transportion tank truck | |||||
| Main Data | Model No. | CLW5310GNYC3 | Axles | 3 | |
| G.V.W(Kg) | 31000 | Tank volume(m3) | 18.52 | ||
| Curb weight(Kg) | 12805 | Overall dimension (mm) | 11990x2500X3650 | ||
| Rated weight(Kg) | 18000 | Axles Load(Kg) | 6500/6500/18000 | ||
| Emission Standard | Euro III | Front/rear suspension(mm) | 1375/2565,1375/2865 | ||
| Approach/departure angle (°) | 25/7 | Front/rear Tread(mm) | 1928/1928,2020/2020,1950/1950(F) 1847/1847,1830/1830,1847/1847(R) | ||
| Wheelbase(mm) | 1900+4500+1350,2000+4700+1350,1950+4550+1350 | Max speed(Km/h) | 85 | ||
| Leaf of springs | 12/12/10,9/9/12,4/4/10,12/12/-,4/4/-,3/3/11,10/10/11 | Tire | 10.00-20,10.00R20,11.00-20,11.00R20 | ||
| Chassis mode | CA1313P7K1L11T4E | Fuel type | Diesel | ||
| Engine | Type | Brand | Displacement(ML) | Rated Power(Kw) | |
| BF6M1013-28E3 | Sinotruk | 7146 | 216 | ||
| CA6DL1-28E3 | Sinotruk | 7700 | 216/203 | ||
| CA6DL1-28E3F | Sinotruk | 7700 | 209/195 | ||
| CA6DF3-26E3F | Sinotruk | 7120 | 195 | ||
| Gearbox | 9 forwarder,1 reverse gear | Brakes | dual circuit compressed air brake | ||
| Milk tank parameter | Tank Effective Volumn | 18.52 m3 | Inside steel thickness | 3-4mm | |
| Middle layer | polyurethane foam:70-80mm | External material | 304 stainless steel /2mm | ||
| warm preservation ability | ±2-3ºC during 24H | Compartment | 5 as standard | ||
| Manhole | Man way access hole on top of tank;2-4 units manhole | ||||
| Tank materials | high quality food grade stainless steel (Q304/2B) | ||||
| Specical fuction | 1.The milk tank is made up of three layers:outside layer(for physical protection),middle layer(thermal insulation),inner layer tank(for milk filling). 2.Equipped with PIC cleaning &washing device inside the tank, washing lever, washing tube(Φ 38mm ), four or even more rotation sprayer, external water tube.Tank itsellf has wash fuction by little pressure. 3. With thermal insulation fuction to maintain temperature. 4. The tank can bedividedinto several parts according to demand to load differentmaterials | ||||
Our main products:
1. Dump Truck /Tipper Truck/Side Tipper/End Tipper
2. Fire Fighting Truck /Fire Truck /Fire Vehicle /Fire Engine
3. Truck with crane /Truck Mounted Crane
4. LPG Tank Truck Trailer/Oil Tank Truck /Fuel Tanker Truck
5. Water Truck /Water Tank Truck /Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck /Insulated truck/ Refrigeration truck
8. Fecal suction truck /Sewage Suction Truck,
9. Cement Powder Tank truck/ Bulk Cement Truck
10. High-altitude operation truck,
11. Self-loading Garbage Truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer (flat bed trailer /skeleton trailer /dump semi trailer /side wall trailer /low bed trailer /van container trailer /warehouse trailer, etc. )
Any further inquires, feel free to contact me throught below info!
Ms. Belinda Gong
: +86-131 6338 8097
Mobile: +86-138 7288 1075/+86-131 6338 8097
Chengli Special Automobile Co., Ltd
Factory Add: Chengli Automobile Industry Park,Suizhou City,
Hubei Province,P.R.China
Export:Room 3102,Block 7, Fanhai International SOHO Town,
Jianghan District,Wuhan, Hubei Province, China
Hubei Chengli Special Automobile Co., Ltd is a famous specialied manufacturer of trucks for Municipal environmental construction, virescence, petrol medicals, container. Semi-trailers, transportation in China.
We own export licenseand all our truckss have passed ISO9001, ISO16949, GJB9001A Quality Certification and China Compulsory Certification(CCC). Due to the reliable quality and excellent after-sales service, the Brand Chengliwei is popular to worldwide. The trucks has been shipped to Vietnam, Mongolia, Kazakhstan, Uzbekistan, Bangladesh, Korea, Russia, Afghan, Iraq, Angola, Algeria, Nigeria, Congo, Libya, Jordan, Ethiopia, Mozambique, Mali, Niger, Trinidad, Namibia, etc.
Chengli Special Automobile Co., Ltd consisit to insist with "Surviving by the quality, Developing by the reputation, Technology creating new path, Service creating new brand". We aim to" credit, pragmatic, innovative, progressive"， promote the quality, deveope and manufacture more and more special vehicles with good quality and competitive price.
1. Factory Supply:one of the biggest special purpose truck manufacturers in china,more than 300 kinds of special truck for your choice.
2. OEM Ability: according to your demand, material, dimensions, surface color and the logo are optional for you.
3. Good Quality: with ISO CCC BV certification Solid technology, advanced equipments; reliant quality and flexible modes of operation also have strict quality control system,passed the ISO9001-2008 and the 3C (China Compulsory Certification),our brand is china famous brand with good reputation in the market.
4. Best Service: 24-hour hotline and email during communication.
5. Fast Delivery: 5-10 days after payment(most common products), safe and quick delivery.
Packaging:nude with wax.
Shipping:Ro-Ro/Bulk Ship/Container
-
