2 Alxes Dongfeng 5cbm Asphalt Distributor Truck

Basic data:

2 alxes Dongfeng 5cbm Asphalt Distributor Truck
Main parameter	Model No.	CLW5100GLQ3	Emission Standard
	G.V.W(Kg)	9750	Overall dimension (mm)	7080x2300X2650
	Curb weight(Kg)	5600	Rated weight(Kg)	3955
	Axles Load(Kg)	3400/6350	Cabin	3 passengers allowed
Chassis parameter	Chassis model	EQ1110T9ADJ3AC	Tire	8.25-16,8.25R16,7.50-16,7.50R16
	Approach/departure angle (°)	22/10	Front/rear Tread(mm)	1831,1750/1640,1586
	Wheelbase(mm)	3800	Front/rear suspension (mm)	1180/2100
	Leaf of springs	11/9+7,8/10+7	Minimum Ground Clearance (mm)
Engine	Engine model	ISDe140 30	Manufacturer	Dongfeng
	Max. Power(Kw)	103	Displacement(ML)	4500
	Emission standard	GB3847-2005,GB17691-200 Euro III	Fuel	Diesel
Spray Specification	Tank Capacity(m ³ )	4.6	Spray width(mm)	6000
	Materials	Q235A carbon steel	Spray Value(Kg)	0.5-3.0
	Tank Size(mm)	3100/1700/1300	Insulation Thickness(mm)	50

Chengli Special Automobile Co., Ltd, as the "Alibaba Group" in the special vehicle circle, has developed into the biggest professional special vehicle manufacturer of central China starting from scratch since 2004.LPG tank is one of our most advantageous key products which ranks Top 5 in China, excellent engineers and high-grade production equipment as well as strict quality control system can ensure all the tank work well with 10-20 years use life.
about our "Chengli Special Automobile co.,Ltd":3000 Acres(2 million SQM) Factory8000 Workers with Professional Training300 Different Types of Trucks Available for Choice300 Million Total Sales Volume for 2014More Than 10 Years Manufacturing ExperienceOur main products:1. Dump Truck / Tipper Truck/Side Tipper/End Tipper2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine3. Truck with crane / Truck Mounted Crane4. LPG Tank Truck Trailer/Oil Tank Truck / Fuel Tanker Truck5. Water Truck / Water Tank Truck / Water Sprinkler Truck6. Concrete Mixer Truck7. Van truck / Insulated truck/ Refrigeration truck8. Fecal suction truck / Sewage Suction Truck,9. Cement Powder Tank truck/ Bulk Cement Truck10. High-altitude operation truck,11. Self-loading Garbage Truck, garbage compactor truck, sealed garbage truck,12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )Each customer who buy our ChengLi products can enjoy below benifits:1. 3rd party inspection, such as BV, Intertek, etc before sale.2. Spare Parts guarantee : 1. Supplying quick-wearing parts at the truck delivery. 2. Good quality parts produced by the truck manufacturing factory. 3. only charge cost price for customer convenience.3. Free warranty for 3 main components :Enginee, Gearbox, Axles.4. After Sales Service : Email & Phone call tracking for each truck on timely manners, also possible engineer maintenace in customer's Country. Any question, feel free to contact me as belowCatherine YeeTel:+86 18607168573

1. Factory Supply:one of the biggest special purpose truck manufacturers in china,more than 300 kinds of special truck for your choice.

2. OEM Ability: according to your demand, material, dimensions, surface color and the logo are optional for you.

3. Good Quality: with ISO CCC BV certification Solid technology, advanced equipments; reliant quality and flexible modes of operation also have strict quality control system,passed the ISO9001-2008 and the 3C (China Compulsory Certification),our brand is china famous brand with good reputation in the market.

4. Best Service: 24-hour hotline and email during communication.

5. Fast Delivery: 5-10 days after payment(most common products), safe and quick delivery.

Packaging:nude with wax.

Shipping:Ro-Ro/Bulk Ship/Container
