2 Alxes 10cbm Asphalt Distributor Tank

2 alxes 10cbm Asphalt Distributor Tank
Tank Main parameter	Tank effective volumn(m3)	8	shape	Ellipse
	G.V.W(Kg)	15790	Overall dimension (mm)	4200x1960x1540
	Curb weight(Kg)	8120	Rated weight(Kg)	7475
	Axles Load(Kg)	9790	Materials	Q235A
	End plate	Q235A/6mm, by punching
	Spurn water	Q235A/5mm, 20 inch manhole 508MM
	Manhole cover	3 sets of 500mm/Q235 manhole fixed on top of Tank, with breather valve
	Unloading valve	2 sets of DN80 fixed at button of Tank
	Pipeline	4"seamless steel tube/Q235 100MM
	Labeling system	Oil Type Indication
	Anti-static electricity system	pulling, wire carrier, sheet copper (6 sheet, reasonable layout)
Other parts	Ladder	1 unit at front of Tank
	Guard	Zinc galvanizing net
	Oil hose box	Circular single hole tube, 1 unit on each side
	Oil hose	2 unit, 3" x 6mm size in black rubber
	Side guard	cross bar structure
	Rear button guard	Fixed Type
	Work tank deck	Box Type
	Fire extinguisher box	2 unit at back of each side
	Mud guard	trapezoid structure in steel
	Lights and wire	24V, 7 coils with lights for parking, reverse, instruction, head lamp and end lamp
Chassis	Main Beams	Heavy duty and extra durability designed; Opting for high tensile steel Q345B,welded by automatic Submerged-Arc processes
	Painting	1. Sand blasting processing clean rust 2. One coats of anticorrosive 3.Two coats of finish urethane paint 4. Colour as customer choice

Chengli Special Automobile Co., Ltd, as the "Alibaba Group" in the special vehicle circle, has developed into the biggest professional special vehicle manufacturer of central China starting from scratch since 2004.



Our main products:
1. Dump Truck / Tipper Truck/Side Tipper/End Tipper
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck Mounted Crane
4. LPG Tank Truck Trailer/Oil Tank Truck / Fuel Tanker Truck
5. Water Truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage Suction Truck,
9. Cement Powder Tank truck/ Bulk Cement Truck
10. High-altitude operation truck,
11. Self-loading Garbage Truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )


Each customer who buy our ChengLi products can enjoy below benifits:

1. 3rd party inspection, such as BV, Intertek, etc before sale.

2. Spare Parts guarantee :
1. Supplying quick-wearing parts at the truck delivery.
2. Good quality parts produced by the truck manufacturing factory.
3. only charge cost price for customer convenience.

3. Free warranty for 3 main components :Enginee, Gearbox, Axles.

4. After Sales Service : Email & Phone call tracking for each truck on timely manners, also possible engineer maintenace in customer's Country.

Any question, feel free to contact me as below
Catherine Yee
Tel:+86 18607168573

1. Factory Supply:one of the biggest special purpose truck manufacturers in china,more than 300 kinds of special truck for your choice.

2. OEM Ability: according to your demand, material, dimensions, surface color and the logo are optional for you.

3. Good Quality: with ISO CCC BV certification Solid technology, advanced equipments; reliant quality and flexible modes of operation also have strict quality control system,passed the ISO9001-2008 and the 3C (China Compulsory Certification),our brand is china famous brand with good reputation in the market.

4. Best Service: 24-hour hotline and email during communication.

5. Fast Delivery: 5-10 days after payment(most common products), safe and quick delivery.

Packaging:nude with wax.

Shipping:Ro-Ro/Bulk Ship/Container
