Construction Equipments Gr200 Motor Grader

  • Construction Equipments Gr200 Motor Grader
  • USD 15000.50 /Unit
  • 1 Unit
  • 45 Unit
  • 20 days
Contact Supplier
Product Description
Basic specification
Engine modelD6114 ZG14B
Rated power/speed 147kW/2200rpm
Dimension(LxWxH)8932×2625×3470mm
Operating weight(Standard)16000kg
Performance specification
Travelling speed ,forward5811192338 km/h
Travelling speed ,reverse51123 km/h
Tractive force(f=0.75)82KN
Max. gradeability20%
Tire inflation pressure260 kPa
Working hydraulic pressure16 MPa
Transmission pressure1.3~1.8MPa
Operating specification
Max. steering angle of front wheels±50°
Max. lean angle of front wheels±17°
Max. oscillation angle of front axle±15°
Max. oscillation angle of balance box15
frame articulation angle±27°
Min. turning radius using articulation7.3m
Biade
Maximum lift above ground450mm
Maximum depth of cutting500mm
Maximum blade position angle90°
Blade cutting angle28°_70°
Circle reversing rotation360°
Moldboard width X height4270×610mm
Product Images
Construction Equipments Gr200 Motor Grader Images 1
